Table 5. Startup Wizard Instructions, continued
Item Description
17 Hand Reference
18 Auto 1 Control Place
19 Auto 1 Control Reference
20 Bypass Enabled
21 Application Mini-Wizard
Now the Startup Wizard is done. It won't show again when
next power up. If you want to reset it, please set the Startup
Wizard (P13.1.17) or select it from the main menu screen to
enable and cycle the power to the drive.
0 = AI1
1 = AI2
2 = Slot A: AI1
3 = Slot B: AI1
4 = AI1 Joystick
5 = AI2 Joystick
6 = Keypad
7 = Fieldbus
9 = Max Frequency
10 = AI1 + AI2
11 = AI1 –AI2
12 = AI2 –AI1
13 = AI1 * AI2
14 = AI1 or AI2
15 = Min(AI1,AI2)
16 = Max(AI1,AI2)
17 = PID1 Control Output
18 = PID2 Control Output
0 = I/O Terminal Start 1
1 = Fieldbus
2 = I/O Terminal Start 2
3 = Keypad
0 = AI1
1 = AI2
2 = Slot A: AI1
3 = Slot B: AI1
4 = AI1 Joystick
5 = AI2 Joystick
6 = Keypad
7 = Fieldbus
9 = Max Frequency
10 = AI1 + AI2
11 = AI1 –AI2
12 = AI2 –AI1
13 = AI1 * AI2
14 = AI1 or AI2
15 = Min(AI1,AI2)
16 = Max(AI1,AI2)
17 = PID1 Control Output
18 = PID2 Control Output
0 = Disabled
1 = Enabled
Press OK?
