Appendix

Messages and error reference

All messages are shown in abbreviated form in
the VLT LCP display.
You can find brief information on the error
messages in the table or detailed information in
the section following the table.

Table of error messages

The table contains
messages in numerical order.
O.ERR LCP DISPLAY
5 ERROR NOT CLEARED
8 POSITION ERROR
9 INDEX NOT FOUND
13 VLT NOT READY
16 PARAM. ERROR EEPROM
17 PROGR. ERROR EEPROM
18 RESET BY CPU
92 ENCODER ERROR
xx INTERNAL ERROR
70
Synchronizing controller
Error messages in detail
As in the table above, the messages are in numerical
order: here you will find additional notes on possible
causes of errors as well as tips for clearing errors.
O.ERR_5
Error not cleared
Cause
An attempt was made to execute a command to
the error
move, although an existing error message had not
been erased.
O.ERR_8
Position error
Meaning
The interval between the reference position and the
feedback position was greater than defined in
Tolerated Position Error Parameter.
Causes
Mechanically blocked or overloaded drive, tolerated
position error too small, reference speed greater than
VLT Parameters 202 and 205, reference acceleration
too great,
Proportional factor too low or VLT not released.
O.ERR_9
Index pulse (encoder) not found
Meaning
During a reference or index search, the encoder
index pulse could not be found within one encoder
rotation.
Causes
A encoder without an index pulse is being used, the
index pulse is not correctly connected, incorrect index
pulse, or the encoder resolution has been set too low.
MG.10.N4.02 - VLT is a registered Danfoss trademark
