O4 - Brake control
4
O5 - Saving
5
6 O6 - Drive running
O7 - Home reached
7
8 O8 - Ready, no error
24V DC
9
COM
10
Option card MK3D (slave encoder)
5V DC
1
COM
2
A1
3
/A1
4
5 B1
/B1
6
Z1
7
8 /Z1
MG.10.N4.02 - VLT is a registered Danfoss trademark
Synchronizing controller
This output can be used to control a mechanical brake.
"0" means that the brake must be closed (braking)
"1" means that the brake must be open (not braking)
This output stays high while saving is in progress. The saving is
initiated by Parameter 710, Input 4 or fieldbus bit 4.
Signal "1" when the drive is running.
Synchronous operation; Program 2:
If the data value "1" or "2" was chosen in Parameter 729, this
output shows "1" homing is completed.
The Synchronizing controller is ready for operation.
Encoder supply
Encoder supply
Incremental encoder
A-track
A-track inverted
B-track
B-track inverted
Zero-track
Zero-track inverted
Absolute encoder
Clock out
Clock out inverted
Data in
Data in inverted
Not used
Not used
