I8 - measuring of the
8
slave marker interval
I8 - VLT mode
selection
24V DC
9
COM
10
Option card MK3B (master encoder)
1 5V DC
COM
2
3 A1
/A1
4
B1
5
/B1
6
Z1
7
/Z1
8
Option card MK3C
O1 - READY
1
O2 - FAULT
2
O3 - ACCURACY
3
18
Synchronizing controller
Test run; Program 1:
Measurement of the slave marker interval is started.
Synchronous operation; Program 2: Switches the VLT to normal
frequency converter operation. The settings for this operating
mode are to be made in Parameter set 2. Refer to the VLT 5000
Product Manual.
Encoder supply
Encoder supply
Incremental encoder
A-track
A-track inverted
B-track
B-track inverted
Zero-track
Zero-track inverted
Synchronous operation; Program 2:
Ready, i.e. for the number of marker signals that were specified in
Parameter 735, the slave drive has run within the tolerance
(Accuracy).
Synchronous operation; Program 2:
Fault, i.e. for the number of marker signals that were specified in
Parameter 734, the slave drive has run outside the tolerance
(Accuracy). OR when the number of marker signals have been
missing when marker monitor is activated in parameter 757.
Synchronous operation; Program 2:
The drive runs within the tolerance specified in Parameter 733.
MG.10.N4.02 - VLT is a registered Danfoss trademark
Absolute encoder
Clock out
Clock out inverted
Data in
Data in inverted
Not used
Not used
