25.3. USB
Figure: Mini USB connector
Waspmote's USB power sources are:
-
USB to PC connection
-
USB to 220V connection
-
USB to Vehicle connector connection
The charging voltage through the USB has to be 5V.
The maximum charging current through the USB is 100mA.
The mini USB connector must be standard mini USB model B.
Figure: Possible connections for the USB
-125-
Power supplies
v6.3
