Fcc - Libelium Waspmote Technical Manual

Certifications

29.2. FCC

Waspmote models:
Model 1- FCC (XBee PRO series 1 OEM + SIM900 GSM/GPRS module)
FCC ID: XKM-WASP01 comprising
- FCC ID: OUR-XBEEPRO
- FCC ID: UDV-0912142009007
Model 2- FCC (XBee PRO ZB series 2 + SIM900 GSM/GPRS module)
FCC ID: XKM-WASP02 comprising
- FCC ID: MCQ-XBEEPRO2*
- FCC ID: UDV-0912142009007
Model 3 - FCC (XBee 900MHz + SIM900 GSM/GPRS module)
FCC ID: XKM-WASP03 comprising
- FCC ID: MCQ-XBEE09P
- FCC ID: UDV-0912142009007
Installation and operation of any Waspmote model must assure a separation distance of 20 cm from all persons, to
comply with RF exposure restrictions.
Module Grant Restrictions
FCC ID OUR-XBEEPRO
The antenna(s) used for this transmitter must be installed to provide the separation distances, as described in this filing, and
must not be co-located or operating in conjunction with any other antenna or transmitter. Grantee must coordinate with OEM
integrators to ensure the end-users of products operating with this module are provided with operating instructions and
installation requirements to satisfy RF exposure compliance. Separate approval is required for all other operating configurations,
including portable configurations with respect to 2.1093 and different antenna configurations. Power listed is continuously
variable from the value listed in this entry to 0.0095W
FCC ID MCQ-XBEEPRO2
OEM integrators and End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
The instruction manual furnished with the intentional radiator shall contain language in the installation instructions informing
the operator and the installer of this responsibility. This grant is valid only when the device is sold to OEM integrators and the
OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device.
FCC ID: UDV-0912142009007
This device is to be used in mobile or fixed applications only. For other antenna(s) not described in this filing the antenna
gain including cable loss must not exceed 7.3 dBi in the 850 MHz Cellular band and 12.7 dBi in the PCS 1900 MHz band, for
the purpose of satisfying the requirements of 2.1043 and 2.1091. The antenna used for this transmitter must be installed to
provide a separation distance of at least 20 cm from all persons, and must not be co-located or operating in conjunction with
other antennas or transmitters within a host device, except in accordance with FCC multi- transmitter product procedures.
Compliance of this device in all final product configurations is the responsibility of the Grantee. OEM integrators and end-users
must be provided with specific information required to satisfy RF exposure compliance for all final host devices and installations.
-167- v6.3
