Figure: Star topology
Regarding the "Energy" section, the transmission power can be adjusted to several values:
Figure: Transmission power values
Figure: XBee-PRO TX Power
Related API libraries: WaspXBeeCore.h, WaspXBeeCore.cpp, WaspXBee802.h, WaspXBee802.cpp
All information about their programming and operation can be found in the document: 802.15.4 Networking Guide.
All the documentation is located in the
Parameter
0
1
2
3
4
Development section
in the Libelium website.
-69-
Tx XBee-PRO
10dBm
12dBm
14dBm
16dBm
18dBm
802.15.4/ZigBee
v6.3
