Single
This variant includes a Single Junction Reference Probe, so it can read all the single type ion sensors.
Sensor sockets are configured as shown in the table below.
Sensor
Socket
A, B, C and D
E
F
Figure: Sensor sockets configuration for Smart Water Ions model, single variant
Note: For more technical information about each sensor probe go to the
Sensor probes allowed for each sensor socket
Parameter
Calcium Ion (Ca )
2+
Fluoride Ion (F )
-
Fluoroborate Ion (BF )
-
4
Nitrate Ion (NO )
-
3
pH (for Smart Water Ions)
Single Junction Reference
Soil/Water Temperature
-29-
Waspmote Plug & Sense! - Encapsulated Line
Reference
9352
9353
9354
9355
9363
9350 (included by default)
9255 (included by default)
Development section in Libelium website.
