Libelium Waspmote Technical Manual page 119

GPRS+GPS
Connecting
Calling
Receiving Calls
Transmitting GPRS
SLEEP
OFF
GPS acquisition mode
GPS tracking mode
3G/GPRS
Connecting
Transmitting/Receiving GPRS
Transmitting/Receiving 3G
SLEEP
OFF
SD
ON 0.14mA
Reading 0.2mA
Writing 0.2mA
OFF 0μA
Accelerometer
Sleep 0,08mA
Hibernate 0,65mA
OFF ~0μA
~100mA
~100mA
~100mA
~100mA
1mA
~0μA
72mA
67mA
~100mA
~100mA (1.2A – 2A during transmission slot every 4.7ms )
~300mA - 500mA
1mA
~0μA
-119-
Energy Consumption
v6.3
