Over the Air Programming is also possible once the node has been installed. With this technique you can reprogram wirelessly
one or more Waspmote sensor nodes at the same time by using a laptop and the Waspmote Gateway.
Figure: Typical OTAP process

2.1.5. Radio Interfaces

Model
XBee-802.15.4-Pro
XBee-ZB-Pro
XBee-868
XBee-900
LoRaWAN
LoRa
Sigfox
WiFi
GPRS Pro and GPRS+GPS
3G/GPRS
Bluetooth Low Energy
* Line of sight, Fresnel zone clearance and 5dBi dipole antenna.
Protocol Frequency
802.15.4 2.4GHz
ZigBee-Pro 2.4GHz
RF 868MHz
RF 900MHz
868, 900 and 433 MHz
LoRaWAN
bands
RF 868 and 900 MHz
Sigfox 868MHz
802.11b/g 2.4GHz
850MHz/900MHz/
-
1800MHz/1900MHz
Europe version: Dual-
band UMTS, tri-band
GSM/GPRS/EDGE
- America/Australia
version: Dual-Band:
UMTS, quad-Band GSM/
GPRS/EDGE
Bluetooth v.4.0 /
2.4GHz
Bluetooth Smart
Waspmote Plug & Sense! - Encapsulated Line
txPower
100mW
50mW
315mW
50mW
up to 18.5 dBm
14 dBm
14 dBm
0dBm - 12dBm
2W(Class4) 850MHz/900MHz,
1W(Class1) 1800MHz/1900MHz
UMTS 0.25 W,
GSM 2 W,
DCS/PCS 1 W
3dBm
-17-
Sensitivity Range *
-100dBm 7000m
-102dBm 7000m
-112dBm 12km
-100dBm 10Km
- km - Typical
base station
-136dBm
range
-137dBm 21+Km
- km - Typical
-126dBm base station
range
-83dBm 50m-500m
- Km - Typical
-109dBm
carrier range
- Km - Typical
-106dBm
carrier range
-103dBm 100m
