Sensor sockets are configured as shown in the figure below.
Sensor
Socket
B
C
D
E
F
Figure: Sensor sockets configuration for Smart Water model
Note: For more technical information about each sensor probe go to the
Sensor probes allowed for each sensor socket
Parameter
pH
Oxidation-Reduction Potential (ORP)
pH
Oxidation-Reduction Potential (ORP)
Soil/Water Temperature
Dissolved Oxygen (DO)
Conductivity
Turbidity
Waspmote Plug & Sense! - Encapsulated Line
Reference
9328
9329
9328
9329
9255 (included by default)
9327
9326
9353
Development section
-27-
in Libelium website.
