802.15.4/ZigBee
Figure: Tree topology
Regarding the "Energy" section, the transmission power cannot be adjusted, because it is always set to 17 dBm
Related API libraries: WaspXBeeCore.h, WaspXBeeCore.cpp, WaspXBeeZB.h, WaspXBeeZB.cpp
All information about their programming and operation can be found in the document: ZigBee Networking Guide.
All the documentation is located in the
Development section
in the Libelium website.
-71-
v6.3
