Auto Memory
Select the Auto Memory checkbox of the desired input to enable the Auto Memory (see
figure 48 on the previous page). Auto Memory recalls input and image settings for signals
that have previously been applied. When Auto Memory is disabled, the scaler treats every
newly applied input as a new source.
HDCP Authorized
Select the HDCP Authorized checkbox to enable or disable the HDCP Authorized
feature for inputs 2 and 3. This feature determines if a digital input reports as an HDCP
authorized sink to a source.
NOTE: This option is not available for analog input 1.
For source devices that require encryption, enable HDCP Authorized. If HDCP
Authorized is disabled for sources that require encryption (for example, a Blu-ray
player), the output is muted or a warning message is displayed.
Some source devices may encrypt their output even if the source material does not
require HDCP encryption, preventing content from being displayed on a non-HDCP
compliant display. Disable HDCP Authorized to allow the output of the scaler to remain
unencrypted.
Film Detect
Select the Film Detect checkbox of the desired input to enable automatic 3:2, 2:2,
and 24:1 film pulldown detection for NTSC, PAL, SECAM, and 1080i input signals.
Output Configuration panel
The Output Configuration panel contains controls for output resolution and rate,
output format settings, switch transitions, Accu-RATE frame lock (AFL) settings, and
available test pattern selection (see figure 49).
Figure 49. Output Configuration
