Print captured images using a network printer — The Annotator 300 supports
•
connection to a printer on the network, enabling captured images to be sent directly
to the printer without connecting to a PC.
• Configurable Main and Confidence outputs — The outputs can be configured
as separate Main and Confidence outputs with individually controlled visibility of
annotation and OSD graphics.
• HDCP compliant — Fully supports HDCP-encrypted sources, with selectable
authorization for unencrypted content.
User-selectable HDCP authorization — Allows individual inputs to appear HDCP
•
compliant or non-HDCP compliant to the connected source, which is beneficial if the
source automatically encrypts all content when connected to an HDCP-compliant
device. Protected material is not passed in non-HDCP mode.
• Supported HDMI specification features include data rates up to 6.75 Gbps, Deep
Color, and HD lossless audio formats.
• Supports DisplayPort input signals at resolutions up to 2560x1600.
• Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for
optimal performance.
• Compatible with CATx shielded twisted pair cable — The Annotator 300 fully
supports a maximum transmission distance of 330 feet (100 meters) for all compatible
resolutions when used with CATx shielded twisted pair cable. Shielded twisted pair
cabling with solid center conductor sizes of 24 AWG or better is recommended for
optimal performance.
• Bidirectional RS-232 and IR pass-through for AV device control — Bidirectional
RS-232 control and IR signals can be transmitted alongside the video signal over
the DTP connection, allowing the remote device to be controlled without the need
for additional cabling. Bidirectional control extension eliminates the need for control
system wiring to remote devices.
• Remote powering of DTP receiver — The Annotator 300 can provide remote
power to a DTP receiver over the twisted pair connection, eliminating the need for a
separate power supply at the remote unit.
• Compatible with all DTP 230 and DTP 330 Series receivers, and DTP-enabled
products — Enables mixing and matching with desktop and wallplate receivers, as
well as other DTP-enabled products to meet application requirements.
• DTP output is compatible with HDBaseT-enabled devices — The DTP output
can be configured to send video and embedded audio, plus bidirectional RS-232 and
IR signals to an HDBaseT-enabled display.
• Auto-switching between inputs — Auto-switching allows for simple, unmanaged
installation in locations such as in a lectern or under a conference table. When
multiple inputs are active, the switching priority is configurable.
Auto Input Format Detection — For the universal analog video input, the
•
Annotator 300 detects the incoming signal format, automatically reconfiguring itself
to provide the appropriate decoding and signal processing. This feature can reduce
the number of required outputs for a matrix switcher, lowering system cost while
improving manageability.
• Selectable output rates from 640x480 to 1920x1200, including 1080p/60 and
2K — Available output rates include computer and video up to 1920x1200, including
1080p/60 and 2K.
