Figure 37. Adding Devices to Restore
To add devices to the list:
a. Enter the IP address, password (where appropriate), and Telnet port details for
each desired target device.
b.
Click Add. The list is populated with the device details.
c. Repeat steps a and b for each desired target device.
d. Click Restore when done adding devices.
Once the list is complete, targets can be selected for deployment. As a default,
all targets are preselected for deployment and have a check mark to the left of the
device details list.
NOTE: PCS verifies the correct Annotator 300 model, IP address, Telnet port,
and device administrator password for each device in the list upon restoring the
configuration. PCS does not push the configuration to the device if one of the
above criteria is not valid and this is reflected in the Status column.
The user may need to click the Edit logo to correct the settings. In addition if a
device is not connected, not powered, or turned off, a "Device not found" status
is returned.
4.
Click the Open Backup File button on the Restore To Multiple Devices
window (see figure 38). An Open Backup File window opens.
Figure 38. Open Backup File
NOTE: If communication setting are not included, only the device audio and video
settings are restored.
Annotator 300 • Product Configuration Software 75
