Annotator 300 Menu System
The Annotator 300 can be configured using the menu system, via the Extron Simple
Instruction Set (SIS) of commands, or via the Extron Products Configuration Software
(PCS 3.0 or higher) software program, through an RS-232 or LAN connected PC.
NOTE: For other methods to configure the menu, see
The Annotator 300 has six front panel configuration menus: User Presets, Picture
Control, Input Configuration, Output Configuration, Advanced
Configuration, and View Comm Settings (see figure 8). A hidden menu (Edit
Comm Settings) is also accessible. Figure 9, on the next page, shows a full menu
overview.
Figure 8.

Overview of Menus

User Presets
This menu allows the user to save the current image settings to a preset number (1-16),
and recall any saved preset to become the current image settings. Each input has sixteen
user selectable presets.
Picture Control
This menu allows configuration of the following settings for an active input: horizontal and
vertical centering and sizing, brightness, contrast, tint, color. and detail.
Input Configuration
This menu allows configuration of the following settings for any selected input: input type,
film detection, vertical and horizontal start points, pixel phase, the number of total and
active pixels, and input EDID value (see
Output Configuration
This menu allows configuration of the following settings for the active output: resolution
and refresh rate (see
Advanced Configuration
This menu allows advanced configuration of the following Annotator 300 settings: test
pattern, calibrate panels, auto image, aspect ratio, auto memory, capture/recall format,
overscan, switch type, internal temperature, and reset to factory defaults.
View Comm Settings
This menu allows the user to view the following serial and IP settings for the unit: serial
port baud rate, MAC address, DHCP (Dynamic Host Configuration Protocol) setting, IP
address, subnet mask address, and gateway address.
NOTE: Communication (Comm) settings can not be edited from within this menu (see
Control starting on page 33 and
page 65 .
User Picture
Menu
Presets
Control
Advanced
Menu
Configuration
The Annotator 300 Front Panel Configuration Menus
figure 12
Edit Comm Settings (Hidden)
SIS Communication and
Product Configuration Software
Input
Menu
Configuration
View Comm
Menu
Settings
figure 10 and figure 11
on page 21), HDMI format, and HDCP note.
on next page).
Annotator 300 • Operation
