ILLKO REVEXplus USB User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
REVEX plus
REVEX plus USB
Version 5.0-R2 ENG
04/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REVEXplus USB and is the answer not in the manual?

Questions and answers

Related Manuals for ILLKO REVEXplus USB

Summary of Contents for ILLKO REVEXplus USB

  • Page 1 USER’S MANUAL REVEX plus REVEX plus USB Version 5.0-R2 ENG 04/2019...

  • Page 2: Table Of Contents

    4.7.2. Current consumption measurement ................26   4.7.3. Current measurement by means of current clamp - .......... 27    – 4.8. Active power consumption, apparent power consumption and cos P, S ..28 Copyright © 2006–2019 ILLKO, s.r.o.
  • Page 3 5. ADDITIONAL INFORMATION ..........31 5.1. Displayed messages ......................31 5.2. Reset of the instrument ....................32 5.3. Communication with PC (REVEXplus USB only) ............. 32 5.4. Maintenance ........................32 5.5. Calibration and service ....................32 5.6. Ecology ........................... 33 6.

  • Page 4: Introduction

    REVEXplus, REVEXplus USB 1. INTRODUCTION All information, instruction and warnings stated in this User’s Manual are applicable both for REVEXplus and REVEXplus USB unless otherwise stated. 1.1. Safety Read this User’s Manual carefully and completely and follow all instructions contained therein. Otherwise using of the instrument may be dangerous for...

  • Page 5: General Description

    • Measurement of PE current during operation and differential leakage current of three-phase portable appliance by means of optional adapters. • USB communication (REVEXplus USB only). The REVEXplus has furthermore additional features, which improves the safety of both operator and the equipment under test: •...

  • Page 6: Applied Standards

    (START) indicator selected measuring mode. Press and release the relevant key. Press and release the relevant key repetitively for the purpose of switching between its several functions. Press the relevant key and hold it pressed. Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 7: Description Of The Instrument

    REVEXplus, REVEXplus USB 2. DESCRIPTION OF THE INSTRUMENT 2.1. Front panel and rear panel 31-33 21-29 9-18 PROTECT P ,S  START HO LD Ca l LO CK Fig. 1 – Front panel and rear panel Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 8: Terminals

    Power supply cord. – insulation resistance / substitute leakage current test terminal. EXT INPUT – current clamp / three-phase adapter / other adapters connector. USB connector (REVEXplus USB only). 2.3. Keyboard and indicators Keyboard – each key selects one or more functions R...

  • Page 9: Included In The Set

    • Calibration certificate. • USB cable A-B (REVEXplus USB only). • CD with USB drivers (REVEXplus USB only). 2.5. Optional accessories Carrying bag • P 6080 – bag for instrument and some accessories. It enables measurement with instrument hung around operator’s neck.
  • Page 10 User’s Manual REVEXplus, REVEXplus USB Special accessories for REVEXplus USB only • P 9020 – Barcode reader with PS/2 connector; barcode reader connects to a PC (USB barcode reader is available, too). • P 9060 – Stick-on label with barcode.

  • Page 11: Putting Into Operation

    Press the CAL key and release it. The (CAL) indicator lights up. • Press the START key and release it. The test starts. After it is finished, the result is • displayed and the (CAL) indicator turns off. Copyright © 2006–2019 ILLKO, s.r.o.
  • Page 12 If the value 2.000 M ÷ 2.600 M is displayed, the insulation resistance measurement is correct. If the value 0.090 mA ÷ 0.110 mA is displayed, the leakage current measurement is correct. Contact service if the test results differ from the ones described above. Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 13: Measurements

    The result of measurement is displayed. • Continuous measurement – press the START key; measurement is in progress and current measured values are displayed until the START key is released. Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 14: Hold Function

    The compensation constant remains in instrument’s memory even if the instrument is switched off. And so the lead compensation is valid until new compensation is carried out.     LOC K ST ART Fig. 3 – Test lead resistance compensation Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 15: Earth Bond Measurement

    PE terminal by means of optional test lead P2012 + crocodile clip P4012. Hard-wired appliance – firstly disconnect appliance from mains! Connect its point of PE connection to the instrument’s PE terminal by means of optional test lead P2012 + crocodile clip P4012. Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 16: Insulation Resistance

    Step 1 - preparation for measurement function: pres the R  key and release it. Symbol „- -“ is displayed • Select the R and indicators (R ) and (M) light up. • Connect tested appliance: Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 17: Substitute Leakage Current

    Test voltage is max. 230 V / 50 ÷ 60 Hz, short circuit current is about 3.5 mA. 4.4.1. Protective class I appliances    Function selection  Connect tested appliance; its mains Appliance connecting switch must be switched on Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 18: Protective Class Ii Appliances - Substitute Touch Leakage Current

    Connect tested appliance; its mains switch must be switched on Appliance connecting Press the test tip connected to the I terminal against exposed conductive part of tested appliance Measurement ST ART ST ART Fig. 7 – Substitute touch leakage current measurement Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 19: Pe Current During Operation

    1. This status is indicated by displaying „Prot“ message; the indicator (PROTECT) turns on, too.    Function selection  PRO TEC T Connect tested appliance to Connect tested appliance test socket 1 Copyright © 2006–2019 ILLKO, s.r.o.
  • Page 20 (INV). Press the START key. It is recommended to lock the measurement - press the • START key and then press the LOCK key. Release both keys. The presence of Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 21: Three-Phase And Hard-Wired Appliances - Ext

    After finishing of measurement (the (START) indicator turns off) the last measured value of leakage current is displayed. • Switch off tested appliance’s mains switch.    I NV Function selection  PROTEC T Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 22: Touch Leakage Current

    Touch leakage current can be measured by methods described in chapters 4.4. and 4.5. The measurement of substitute touch leakage current is described in chapter 4.4.2. Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 23: Protective Class Ii Appliances

    (INV). Press the START key. It is recommended to lock the measurement - press the • START key and then press the LOCK key. Release both keys. The presence of Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 24: Protective Class I Appliances

    In such case we recommend not to use the key for its memorizing, but to remember the value which was displayed immediately before pressing of the test tip against exposed conductive part of tested appliance and to subtract it “manually”. Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 25: Mains Voltage And Current Consumption - U, I

    4.7. Mains voltage and current consumption – U, I Function U measures L-N voltage in mains outlet from which the REVEXplus is powered. Function I measures current consumption of tested appliance connected to test socket 1. Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 26: Mains Voltage Measurement

      Function selection  Connect tested appliance Connect tested appliance to test socket 1 Test socket 1 energizing ST ART Switch on mains switch of tested Measurement appliance Fig. 14 – Current consumption measurement Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 27: Current Measurement By Means Of Current Clamp -  Ext

    Connect current clamp to the instrument and enclose with its jaws live conductor of Connect current clamp measured appliance. Switch on mains switch of tested appliance Measurement ST ART Fig. 15 – Current measurement by means of current clamp Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 28: Active Power Consumption, Apparent Power Consumption And Cos  - P, S

    P , S Connect tested appliance to Connect tested appliance test socket 1 Test socket 1 energizing ST ART Switch on mains switch of tested Measurement appliance  Displaying of other P , S measured quantities Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 29: Power Consumptions And Cos  Measured By Means Of Current Clamp

    Connect current clamp appliance. Switch on mains switch of tested appliance Measurement ST ART  Displaying of other P , S measured quantities  Fig. 17 – Power consumption and cos measurement by means of current clamp Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 30: Utilization Of Other External Adapters - Ext

    EXT INPUT. If it is activated, the (EXT) indicator lights up and test socket 1 is not functional. It is prohibited to connect any external voltage to the EXT INPUT terminal! Use original accessories only! Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 31: Additional Information

    External voltage > 10 V is present on START key is pressed. + “Prot” displayed tested appliance. measurement – at (PROTECT) Leakage or touch leakage current exceeds  + “Prot” displayed about 12 mA. any time. Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 32: Reset Of The Instrument

    REVEXplus from mains, wait 30 s and plug it in again. If malfunction persists, contact your local distributor. 5.3. Communication with PC (REVEXplus USB only) The Hyperterminal program (which is standard component of Windows installation) is utilized for communication with PC.

  • Page 33: Ecology

    It is made of corrugated board; it is recyclable. Instrument This symbol signifies that the product should not be thrown away to municipal waste at end-of-life. Please dispose of this product according to the relevant statutory requirements. Copyright © 2006–2019 ILLKO, s.r.o.

  • Page 34: Technical Specification

    Operating condition: Line voltage 230V10%/50Hz,60Hz 1% Case resistance to temperature ..... 70C Ambient temperature .... 0C  40C PE test ........... automatic PC connection (REVEXplus USB only).USB 6.2. Functions Earth bond 200 mA Insulation resistance 0.000 ÷ 20.00  0.000 k ÷ 100.0 M...
  • Page 35 These sub ranges are switched over automatically. Copyright © 2006-2019, ILLKO, s.r.o. No part of this publication may be reproduced or utilized in any form or by any means without permission in writing from ILLKO, s.r.o. Copyright © 2006–2019 ILLKO, s.r.o.
