ILLKO GIGATEST pro User Manual

Hide thumbs Also See for GIGATEST pro:

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
GIGATEST pro
V 3.1-EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the GIGATEST pro and is the answer not in the manual?

Questions and answers

Related Manuals for ILLKO GIGATEST pro

Summary of Contents for ILLKO GIGATEST pro

  • Page 1 USER’S MANUAL GIGATEST pro V 3.1-EN...

  • Page 2: Table Of Contents

    GIGATESTpro Table of Contents 1. INTRODUCTION................3 1.1. Safety ..................3 1.2. General description of the instrument .......... 4 1.3. Standards applied ............... 4 1.4. Ecology ..................4 2. DESCRIPTION OF THE INSTRUMENT ......... 5 2.1. Instrument’s case ................ 5 2.2.

  • Page 3: Introduction

    GIGATESTpro 1. INTRODUCTION 1.1. Safety Read this User’s Manual carefully and completely and follow all instructions contained therein. Failure to comply with all warnings and instructions may result in serious damage or destruction of the measuring instrument, damage to the object being measured, or even electric shock! Explanation of the symbols on the instruments: Protection class (double insulation)

  • Page 4: General Description Of The Instrument

    GIGATESTpro • The instrument can be used only under conditions that are specified in Technical Specification, see Chapter 5. • Do not expose the instrument to aggressive gases, vapours, liquids and dust. • If you have transferred the unit from cold to hot environment, it can cause the condensation.

  • Page 5: Description Of The Instrument

    GIGATESTpro 2. DESCRIPTION OF THE INSTRUMENT 2.1. Instrument’s case test tip on instrument’s case lighting LED OLED display control panel instrument’s case sliding protective cover movable test tip terminal for connecting socket of movable test tip for accumulators’ charger Fig. 2.1. Top side •...

  • Page 6: Control Panel And Oled Display

    GIGATESTpro the batteries compartment cover screws securing the batteries information label compartment cover Fig. 2.2. Detail of bottom side 2.2. Control panel and OLED display Graphical OLED display Turning on and off: a long press of the START key turns the instrument on, the instrument can be turned off with two short presses.

  • Page 7: Included In The Set

    GIGATESTpro 2.3. Included in the set GIGATESTpro Twisted test lead with measuring tip Pouch User’s Manual Calibration Certificate Cardboard shipping case 2.4. Optional accessories P 5050 – adapter for charging accumulators P 5060 – set of 4 NiMH AAA accumulators P 2011 –...

  • Page 8: Measurements

    GIGATESTpro 3. MEASUREMENTS 3.1. Turning the instrument on and off, power saving mode, auto power off Hold the START key pressed until the device turns on. The instrument is turned off after two short pressing/releasing the START button, while no voltage can be applied on the test tips. The instrument enters power saving mode (reduced display brightness) after about 30 s of inactivity (no key pressed, no voltage applied on the test tips).

  • Page 9: Measurements Of The Particular Functions

    GIGATESTpro • Before starting the measurement by the START key reliably connect the test tips with the measured object. During the measurement neither early disconnect the test leads nor interrupt the connection with the measured object. Doing so may cause displaying of incorrect values. Fig.

  • Page 10: Voltage

    GIGATESTpro 3.3.1. Voltage • Connect the instrument to object under test. Example of connection: Fig. 3.3 Example of connection • If voltage applied on the test tips is > about 10 V, its value is displayed in the area. For AC voltage, symbol ”~” is displayed. For DC voltage, symbol “+” is displayed if the test tip on instrument’s case is connected to +, or “-”...

  • Page 11: Insulation Resistance

    GIGATESTpro 3.3.2. Insulation resistance • Set R function by the R key: Fig. 3.5 Example of setting for insulation resistance measurement • By the  U and  U keys select the desired nominal test voltage. TEST TEST By short-clicks of the  U ...
  • Page 12 GIGATESTpro switch is off Fig. 3.6 Example of connection Note: If voltage applied on the test tips is > about 10 V, its value is displayed and the START key does not start the measurement. See the Chapter 3.3.1. for details. Disconnect applied voltage; only then you can continue in measurement! •...

  • Page 13: Overvoltage Protection Devices (Opds)

    GIGATESTpro Fig. 3.7a Example of R Fig. 3.7b Example of R measurement result measurement result (discharged) (discharging in progress) Note: Instrument may make a hissing or whistling sound during measurement. • If there is a varistor SPD or a GDT in the circuit where the insulation resistance is measured, then the instrument will display the symbol of the varistor SPD and the so-called “voltage at the milliampere point”...
  • Page 14 GIGATESTpro magnitude of the voltage just before its sudden drop is breakdown voltage of the GDT. Based on the characteristics of the measured voltage over the course of the measurement, the instrument automatically determines whether a GDT or a varistor SPD was measured. The FUNC key can be used to select the measurement mode of the OPD: –...
  • Page 15 Data on specific types of OPDs are stored in the instrument's memory, were obtained from individual manufacturers of OPDs and cannot be edited. Note: An up-to-date list of OPD types stored in the instruments' memory can be published at www.illko.cz and/or www.illko.com. Marking of OPD Connection mode Protection type GDT breakdown...
  • Page 16 GIGATESTpro the table is deleted. When repeatedly measuring the same type of OPD, the item is not saved repeatedly. If an item is measured that is already in the table of the last ten measured types, it is only moved to the first place of the table. If any item from the last ten measured types of OPDs is shown on the display, it is possible to block further saving in this table by pressing the R key.
  • Page 17 GIGATESTpro Actual voltage on Measurement The upper limit the test tips evaluation of the OPD voltage Symbol of the measured Measured varistor voltage Symbol of the mea- element – varistor SPD sured element – GDT or GDT breakdown voltage Fig. 3.10 An example of displaying the measurement result of the selected OPD on the device display Notes on the practical execution of OPD measurements: •...
  • Page 18 GIGATESTpro that case, perform a second (control) measurement immediately afterwards. → PEN → PEN → PEN We measure: Fig. 3.11 Example of varistor SPD 3+0 block measurement B) OPD measurement - manual setting of limits OPD measurement procedure: • Use the R key to select OPD measurement.

  • Page 19: Other Functions Of The Instrument

    GIGATESTpro • The symbol of the measured element (varistor SPD or GDT) will appear in the lower left corner of the display. The display shows the measured voltage and the evaluation of the measurement (see table 1). Note: Do not disconnect the device from the measured OPD while the warning symbol is displayed “!“.

  • Page 20: Reset Of The Instrument

    GIGATESTpro 3.5. RESET of the instrument If the instrument does not work correctly as described in this manual, we recommend RESET: The instrument has to be turned off and both test tips disconnected from any circuit! If you turn the instrument on and it will not restore its proper function, then remove batteries –...

  • Page 21: Maintenance

    GIGATESTpro 4. MAINTENANCE 4.1. Batteries Dangerous voltage in batteries compartment! Disconnect both test tips from tested object and turn off the instrument before removing the batteries compartment cover or before connecting jack to the socket for accumulator charger! The instrument must not be put into operation without the batteries compartment cover properly fastened by both screws! The instrument uses four AAA either alkaline cells or NiMH accumulators.

  • Page 22: Charging Of Accumulators

    GIGATESTpro 4.1.2. Charging of accumulators For charging of accumulators use only adapter supplied as optional accessories! Accumulators are charged as soon as the adapter is connected to mains and to socket for accumulators charger (see Fig. 2.1). If accumulators are fully discharged, the charging takes about 6 hours (applies to batteries with a capacity of 800 mAh).

  • Page 23: Cleaning

    Measuring instruments should be regularly calibrated. We recommend interval of calibration 1 year. Furthermore, we recommend carrying out calibration after each repair. Contact your local distributor for further information. 4.4. Service Manufacturer, service: ILLKO, s.r.o. Masarykova 2226 678 01 Blansko Czech Republic tel./fax: +420 516 417 355 e-mail: illko@illko.cz...

  • Page 24: Technical Specification

    GIGATESTpro 5. TECHNICAL SPECIFICATION 5.1. Functions Insulation resistance R Operating range of use @ EN 61557-2: 0,100 MΩ ÷ Rmax* Measuring Resolution Reference error Operating error range 0,100 MΩ  (2 % of R + 10 D) (3 % of R + 20 D) 0,001 MΩ...

  • Page 25: General Data

    80 % (40 ÷ 70) °C (noncondensing) instrument’s position arbitrary Copyright © 2024, ILLKO, s.r.o. No part of this publication may be reproduced or utilized in any form or by any means without permission in writing from ILLKO, s.r.o. - 25 - 10/24-V3.1-EN...
