- Page 1 USER’S MANUAL ZEROTEST pro V 2.0-EN...
-
Page 2: Table Of Contents
ZEROTESTpro Table of Contents 1. INTRODUCTION................3 1.1. Safety ..................3 1.2. General description of the instrument .......... 4 1.3. Standards applied ............... 5 1.4. Ecology ..................5 2. DESCRIPTION OF THE INSTRUMENT ......... 6 2.1. Instrument’s case ................ 6 2.2. -
Page 3: Introduction
ZEROTESTpro 1. INTRODUCTION 1.1. Safety Read this User’s Manual carefully and completely and follow all instructions contained therein. Otherwise using of the instrument may be dangerous for operator, for installation under test under test or for the instrument! Explanation of the symbols on the instruments:... -
Page 4: General Description Of The Instrument
1.2. General description of the instrument The ZEROTESTpro is a compact instrument with a unique system for storing the test tips in the transport position – sharp tips are safely hidden. High contrast bright multicolour graphic OLED display ensures excellent legibility. -
Page 5: Standards Applied
ZEROTESTpro 1.3. Standards applied Measurements: EMC: Safety: ČSN EN 61557-1 ČSN EN 55022, class B ČSN EN 61010-1 ČSN EN 61557-3 ČSN EN 61326-1 ČSN EN 61010-2-031 ČSN EN 61000-4-2,3,4,5,6 1.4. Ecology Shipping case It is made of cardboard and is recyclable. Please hand it to a collection point of secondary raw materials in accordance with local regulations. -
Page 6: Description Of The Instrument
ZEROTESTpro 2. DESCRIPTION OF THE INSTRUMENT 2.1. Instrument’s case test tip on instrument’s case OLED display instrument’s case sliding protective cover movable test tip control panel terminal for connecting of movable test tip socket for accumulators’ charger Fig. 2.1. Top side •... -
Page 7: Control Panel And Oled Display
ZEROTESTpro the batteries / fuse compartment cover screws securing the batteries / information label fuse compartment cover Fig. 2.2. Detail of bottom side 2.2. Control panel and OLED display Graphical OLED display START key starts measurement, if the test tips are connected to a voltage. -
Page 8: Included In The Set
ZEROTESTpro There are two modes how information is displayed in the OLED display: • Basic mode: there are only measured results displayed with big digits. Evaluation of measured results is disabled. • Detailed mode: there are both measured results and data from the database (table) of fuses displayed. -
Page 9: Putting The Instrument Into Operation
ZEROTESTpro 2.5. Putting the instrument into operation Putting the instrument into operation consists of inserting the batteries or accumulators - the procedure is described in the Chapter 4.1. of this manual. - 9 -... -
Page 10: Measurements
ZEROTESTpro 3. MEASUREMENTS 3.1. Turning the instrument on and off, power saving mode, auto power off Hold the START key pressed until the device turns on. The instrument is turned off after two short pressing/releasing the START key, while no voltage can be applied on the test tips. - Page 11 ZEROTESTpro Fig. 3.2 The symbol of blown fuse (Detailed display mode, example) • If a voltage applied on the test tips is in range 190 V ÷ 260 V, TRMS value is displayed and the START key can start the measurement: Fig.
-
Page 12: Fault Loop/Line Resistance Measurement
ZEROTESTpro Fig. 3.5a Indication of high temp. Fig. 3.5b Indication of high temp. (Basic display mode, example) (Detailed display mode, example) If the maximal allowable temperature has been exceeded, the STOP icon is displayed instead of “T” symbol and then you can’t start the measurement by the START key –... - Page 13 ZEROTESTpro • Connect the turned-on instrument to L and PE (Loop measurement) or to L and N (Line measurement). Example of connection for measurement of Loop resistance: Fig. 3.7 Example of connection - measurement of L2-PE Loop resistance • After displayed voltage is stabilized, press and release the START key.
-
Page 14: Function „Rcd
ZEROTESTpro How to display additional measured / calculated results on the display Basic display mode - press and release the DISP▲ or DISP ▼ key. Following results are displayed successively: calculated prospective fault/short-circuit current, measured Loop/Line resistance multiplied by a factor 1.5, Loop/Line resistance result which takes into account the measurement error and finally measured Loop/Line resistance again. - Page 15 ZEROTESTpro • After displayed voltage is stabilized, press and release the ~ / RCD key. The measurement of Line resistance is executed (it is necessary to measure it before Loop resistance measurement is executed). Ensure good contact between the test tips and the measured object. After the measurement is finished, the Line resistance measurement result is displayed and the symbol „~“...
-
Page 16: Automatic Evaluation Of The Measured Loop/Line Resistance
• There is the database (table) of fuses’ types/disconnecting times/rated currents in the memory of the ZEROTESTpro. There are displayed fuse type, rated current and disconnecting time (example in the Fig. 3.16). When the T key is pressed first time, the minimal required fault current is displayed. - Page 17 ZEROTESTpro Fig. 3.17a Phase voltage present on Fig. 3.17b Phase voltage present on the test tip (Basic display mode) the test tip (Detailed display mode) Note: To avoid wrong results, following prerequisites must be met: You have to hold the instrument in hand (palm) in a standard way! You have to stand on non-insulated floor! The test tip has to be connected to a voltage at least 2 seconds.
-
Page 18: Reset Of The Instrument
ZEROTESTpro 3.6. RESET of the instrument If the instrument does not work correctly as described in this manual, we recommend RESET: The instrument has to be turned off and both test tips disconnected from any circuit! If you turn the instrument on and it will not restore its proper function, then remove batteries –... -
Page 19: Maintenance
ZEROTESTpro 4. MAINTENANCE 4.1. Batteries and fuse replacement Dangerous voltage in batteries / fuse compartment! Disconnect both test tips from tested object and turn off the instrument before removing the batteries / fuse compartment cover or before connecting jack to the socket for accumulator... -
Page 20: Charging Of Accumulators
ZEROTESTpro 4.1.2. Charging of accumulators For charging of accumulators use only adapter supplied as optional accessories! Accumulators are charged as soon as the adapter is connected to mains and to socket for accumulators charger (see Fig. 2.1). If accumulators are fully discharged, the charging takes about 6 hours (applies to batteries with a capacity of 800 mAh). -
Page 21: Replacing The Fuse
ZEROTESTpro 4.1.3. Replacing the fuse Replace the fuse by the same type only: F1A/500 V, breaking capacity 1500 A, dimensions 32x6,3 mm. Using of another type of fuse can cause damage of the instrument and/or operator’s safety can no longer be guaranteed! For replacing the fuse unscrew two screws and remove the batteries / fuse compartment cover, see Fig. -
Page 22: Technical Specification
ZEROTESTpro 5. TECHNICAL SPECIFICATION 5.1. Functions Fault Loop Resistance / Line Resistance (Function „~“) Operating range of use @ EN 61557-3: 0,27 Ω ÷ 200 Ω Measuring Resolution (Ω) Reference error Operating error range (Ω) 0,00 4,99 (3 % of R + 5 D) (4 % of R + 7 D) -
Page 23: General Data
ZEROTESTpro Notes to the parameters stated in chapter 5.1: a) Stated accuracy of Loop/Line Resistance and Prospective Fault Current / Short-Circuit Current is valid only if mains voltage is stable during measurement. b) R... Reading, D... Digit. 5.2. General data... -
Page 24: Appendix A - Fuse Table
ZEROTESTpro 6. APPENDIX A – Fuse table Fuse type NV Rated Disconnecting time [s] current Min. prospective short-circuit current (A) 32.5 22.3 18.7 15.9 65.6 46.4 38.8 31.9 18.7 102.8 56.5 46.4 26.7 165.8 115.3 96.5 80.7 46.4 206.9 150.8 126.1... - Page 25 ZEROTESTpro 919.2 464.2 266.9 1217.2 821.7 663.3 319.1 1567.2 1133.1 964.9 836.5 447.9 2075.3 1429 1195.4 1018 585.4 Fuse type B Rated Disconnecting time [s] current Min. prospective short-circuit current (A) Fuse type C Rated Disconnecting time [s] current Min. prospective short-circuit current (A) 10.8...
- Page 26 Min. prospective short-circuit current (A) 10.8 21.6 32.4 70.2 86.4 172.8 Copyright © 2024, ILLKO, s.r.o. No part of this publication may be reproduced or utilized in any form or by any means without permission in writing from ILLKO, s.r.o - 26 -...
