USB-UART Bridge

KitProg2 on the PSoC 6 BLE Prototyping Board can act as a USB-UART bridge. The UART lines
between KitProg2 and the target are hard-wired on the board, through the snappable area, with
UART_RX assigned to P5[0] and UART_TX assigned to P5[1] on target PSoC 6 MCU. For more
details on the KitProg2 USB-UART functionality, see the USB-UART Bridge section in the
User Guide.
Figure 3-5. UART Connection between KitProg2 and EZ-BLE Creator Module
KitProg2
P12[6]
P12[7]
3.4

USB-I2C Bridge

KitProg2 can function as a USB-I2C bridge and communicate with the software utility Bridge Control
Panel (BCP). The I2C lines on target EZ-BLE Creator Module are P6[5] (SDA) and P6[4] (SCL),
which are hardwired on the board to the I2C lines of KitProg2. The USB-I2C bridge supports I2C
speeds of 50 kHz, 100 kHz, 400 kHz, and 1 MHz. For more details on the KitProg2 USB-I2C func-
tionality, see the USB-I2C Bridge section in the
Figure 3-6. I2C Connection between KitProg2 and EZ-BLE Creator Module
KitProg2
P12[0]
P12[1]
3.5

Updating the KitProg2 Firmware

The KitProg2 firmware normally does not require any update. You can use the PSoC Programmer
software to update the KitProg2 firmware if necessary. For a detailed explanation on how to update
the KitProg2 firmware, see Updating the KitProg2 Firmware in the
PSoC® 6 BLE Prototyping Board Guide, Doc. # 002-24993 Rev. **
PSoC 6
TX RX
P5[0]
TX
RX
P5[1]
PSoC 6
SCL
P6[4]
SDA
P6[5]
KitProg2 User Guide.
KitProg2 User
Kit Operation
KitProg2
Guide.
