A.

Appendix

A.1

Board Details

The PSoC 6 BLE Prototyping Board consists of the following blocks:
EZ-BLE Creator Module (CYBLE-416045-02)
■
PSoC 6 MCU I/O headers J1 and J2
■
KitProg2 (PSoC 5LP) device (CY8C5868LTI-LP039)
■
KitProg2 I/O headers J6 and J7
■
SWD connection headers J4 and J5
■
USB 2.0 Micro-B connector J8
■
Power LED, LED1 (amber)
■
KitProg2 Status LED, LED2 (amber)
■
User LED, LED3 (red)
■
User LED, LED4 (green)
■
ECO Crystal (footprint)
■
WCO Crystal (32.768 kHz)
■
One Push Button SW2 (User)
■
One Push Button SW1 (Reset)
■
One Push Button SW3 (KitProg2 Mode)
■
Current Measurement Jumper J3 (foot-print only, shorted by the zero-ohm resistor R28)
■
Perforated 'snappable' board design
■
PSoC® 6 BLE Prototyping Board Guide, Doc. # 002-24993 Rev. ** 26
