VLT Micro Drive FC 51 Operating Instructions
Indicator lights:
•
•
•
Navigation Keys:
[Back]:
Arrows [▲] [▼]:
ters.
[OK]:
Operation Keys:
A yellow light above the operation keys indicates the active key.
[Hand on]:
[Off/Reset]:
[Auto on]:
cation.
[Potentiometer] (LCP12):
which the frequency converter is running.
In Auto Mode
Hand on Mode
In

4.2. Status Menu

After power up the Status Menu is active. Use
the [MENU] key to toggle between Status,
Quick Menu and Main Menu.
Arrows [▲] and [▼] toggles between the
choices in each menu.
The display indicates the status mode with a
small arrow above "Status".

4.3. Quick Menu

The Quick Menu gives easy access to the most frequently used parameters.
1.
2.
3.
4.
5.
6.
Green LED: Power is on the frequency converter.
Yellow LED: Indicates a warning.
Flashing red LED: Indicates an alarm.
For moving to the previous step or layer in the navigation structure.
For manoeuvring between parameter groups, parameters and within parame-
For selecting a parameter and for accepting changes to parameter settings.
Starts the motor and enables control of the frequency converter via the LCP.
The motor stops except in alarm mode. In that case the motor will be reset.
The frequency converter is controlled either via control terminals or serial communi-
The potentiometer works in two ways depending on the mode in
the potentiometer acts as an extra programmable analog input.
the potentiometer controls local reference.
To enter the Quick Menu, press
[MENU] key until indicator in display
Quick Menu
is placed above
press [OK].
Use [▲] [▼] to browse through the
parameters in the Quick Menu.
Press [OK] to select a parameter.
Use [▲] [▼] to change the value of a
parameter setting.
Press [OK] to accept the change.
To exit, press either [Back] twice to
Status
enter , or press [Menu] once
to enter Main Menu .
MG.02.A2.02 - VLT ® is a registered Danfoss trademark
Illustration 4.8: Indicating Status mode
, then
Illustration 4.9: Indicating Quick Menu mode
