4. Programming
1-00 Configuration Mode
Range:
3-02 Min. Reference
Range:
4
3-03 Max. Reference
Range:
3-10 Preset Reference
Range:
4-12 Motor Speed Low Limit
Range:
4-14 Motor Speed High Limit
Range:
6-22 Terminal 60 Low Current
Range:
6-23 Terminal 60 High Current
Range:
6-24 Terminal 60 Low Feedback Value
Range:
20
Function:
[] Choose [3] Process Closed Loop
Function:
[-4999 - 4999] Sets limits for set-point and feedback.
Function:
[-4999 - 4999] Sets limits for set-point and feedback.
Function:
[-100.00 - 100.00] Preset [0] works as set-point.
Function:
[0.0 - 400 Hz] Lowest possible output frequency.
Function:
[0.0 - 400.00 Hz] Highest possible output frequency.
NB!
Default 65 Hz should normally be reduced to 50 - 55 Hz.
Function:
[0.00 - 19.99 mA] Normally set to 0 or 4 mA.
Function:
[0.01 - 20.00 mA] Normally (default) set to 20 mA.
Function:
[-4999 - 4999] Value corresponding to P. 6-22 setting.
