7.2. Other Specifications

Protection and Features:
•
•
•
•
•
•
•
Mains supply (L1/L, L2, L3/N):
Supply voltage
Supply voltage
Supply frequency
Max. imbalance temporary between mains phases
True Power Factor (λ)
Displacement Power Factor (cosφ) near unity
Switching on input supply L1/L, L2, L3/N (power-ups)
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100.000 RMS sym-
metrical Amperes, 240/480 V maximum.
Motor output (U, V, W):
Output voltage
Output frequency
Switching on output
Ramp times
Cable lengths and cross sections:
Max. motor cable length, screened/armoured (EMC correct installation)
Max. motor cable length, unscreened/unarmoured
Max. cross section to motor, mains, load sharing and brake *
Maximum cross section to control terminals, rigid wire
Maximum cross section to control terminals, flexible cable
Maximum cross section to control terminals, cable with enclosed core
Minimum cross section to control terminals
* See tables for mains supply for more information!
Digital inputs (Pulse/enocder inputs):
Programmable digital inputs (Pulse/encoder)
Terminal number
Logic
Voltage level
Voltage level, logic'0' PNP
Voltage level, logic'1' PNP
Voltage level, logic '0' NPN
Voltage level, logic '1' NPN
Electronic thermal motor protection against overload.
Temperature monitoring of the heatsink ensures that the frequency converter trips in
case of overtemperature
The frequency converter is protected against short-circuits on motor terminals U, V, W.
If a motor phase is missing, the frequency trips and issues an alarm.
If a mains phase is missing, the frequency converter trips or issues a warning (depending
on the load).
Monitoring of the intermediate circuit voltage ensures that the frequency converter trips
if the intermediate circuit voltage is too low or too high.
The frequency converter is protected against earth faults on motor terminals U, V, W.
