3. Electrical Installation
FC 51
1 X 200-240 V
kW
0K18
0K37
0K75
1K5
2K2
3
3 x 200-240 V
0K25
0K37
0K75
1K5
2K2
3K7
3 x 380-480 V
0K37
0K75
1K5
2K2
3K0
4K0
5K5
7K5
Table 3.2: Fuses

3.1.3. EMC-Correct Installation

Following these guidelines is advised, where compliance with EN 61000-6-3/4, EN 55011 or EN
61800-3
then it is acceptable to deviate from these guidelines. It is however not recommended.
Good engineering practice to ensure EMC-correct electrical installation:
•
•
•
•
•
•
10
Bussmann Bussmann Bussmann
Type RK1 Type J Type T
- KTN-R15 JKS-15 JJN-15
KTN-R25 JKS-25 JJN-25
KTN-R35 JKS-35 JJN-35
KTN-R45 JKS-45 JJN-45
KTN-R10 JKS-10 JJN-10
KTN-R15 JKS-15 JJN-15
KTN-R20 JKS-20 JJN-20
KTN-R25 JKS-25 JJN-25
KTN-R30 JKS-30 JJN-30
KTN-R45 JKS-45 JJN-45
- KTS-R10 JKS-10 JJS-10
KTS-R15 JKS-15 JJS-15
KTS-R20 JKS-20 JJS-20
KTS-R25 JKS-25 JJS-25
KTS-R30 JKS-30 JJS-30
KTS-R35 JKS-35 JJS-35
KTS-R45 JKS-45 JJS-45
First environment
is required. If the installation is in EN 61800-3
Use only braided screened/armoured motor cables and control cables.
The screen should provide a minimum coverage of 80%.The screen material must be
metal, not limited to but typically copper, aluminium, steel or lead. There are no special
requirements for the mains cable.
Installations using rigid metal conduits are not required to use screened cable, but the
motor cable must be installed in conduit separate from the control and mains cables. Full
connection of the conduit from the drive to the motor is required. The EMC performance
of flexible conduits varies a lot and information from the manufacturer must be obtained.
Connect the screen/armour/conduit to earth at both ends for motor cables and control
cables.
Avoid terminating the screen/armour with twisted ends (pigtails). Such a termination
increases the high frequency impedance of the screen, which reduces its effectiveness
at high frequencies. Use low impedance cable clamps or glands instead.
Ensure good electrical contact between the de-coupling plate and the metal chassis of
the frequency converter, see Instruction MI.02.BX.YY
Avoid using unscreened/unarmoured motor or control cables inside cabinets housing the
drive(s), where possible.
MG.02.A2.02 - VLT
VLT Micro Drive FC 51 Operating Instructions
Ferraz- Ferraz-
Littel fuse
Shawmut Shawmut
Type RK1 Type CC Type RK1
KLN-R15 ATM-R15 A2K-15R
KLN-R25 ATM-R25 A2K-25R
KLN-R35 - A2K-35R
KLN-R45 - A2K-45R
KLN-R10 ATM-R10 A2K-10R
KLN-R15 ATM-R15 A2K-15R
KLN-R20 ATM-R20 A2K-20R
KLN-R25 ATM-R25 A2K-25R
KLN-R30 ATM-R30 A2K-30R
KLN-R45 - A2K-45R
KLS-R10 ATM-R10 A6K-10R
KLS-R15 ATM-R15 A2K-15R
KLS-R20 ATM-R20 A6K-20R
KLS-R25 ATM-R25 A6K-25R
KLS-R30 ATM-R30 A6K-30R
KLS-R35 - A6K-35R
KLS-R45 - A6K-45R
® is a registered Danfoss trademark
Max. fuses non
UL
Type gG
15A
25A
35A
45A
10A
15A
20A
25A
30A
45A
10A
15A
20A
25A
30A
35A
45A
Second environment
,
