EVOLIO
255
INSTALLER
MANUAL
WATER PURIFICATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Evolio 255 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pentair Evolio 255

  • Page 1 EVOLIO INSTALLER MANUAL WATER PURIFICATION...
  • Page 2: Table Of Contents

    Installer Manual Evolio 255 - Table of content Table of content Generalities ......... . 7 1.1.
  • Page 3 Installer Manual Evolio 255 - Table of content Installation ......... . 24 4.1.
  • Page 4 Installer Manual Evolio 255 - Table of content Commissioning ........50 6.1.
  • Page 5 Installer Manual Evolio 255 - Table of content Maintenance ......... 58 8.1.
  • Page 6 Evolio 255 controller........
  • Page 7: Generalities

    • For domestic use only; • the water softener series Evolio 255 may only and exclusively be used for residential water softening under specified conditions, see 4.3.2. Water, page 24; • the water softener series Evolio 255 protects water pipes and connected water-carrying systems from scaling, respectively from malfunctions and damage caused by scaling;...
  • Page 8: Abbreviations Used And Glossary

    Installer Manual Evolio 255 - Generalities 1.5. Abbreviations used and glossary Refill Controller ........Brine Line Flow Controller DLFC ............Drain Line Flow Controller Regen ............Regeneration 1.6. Norms 1.6.1. Applicable norms Comply with the following guidelines: • 2006/42/EC: Machinery Directive;...
  • Page 9: Procedure For Technical Support

    Pentair Quality System EMEA products benefit, under specific conditions, from a manufacturer warranty that may be invoked by Pentair’s direct customers. Users should contact the vendor of this product for applicable conditions and in case of a potential warranty claim.
  • Page 10: Safety

    Installer Manual Evolio 255 - Safety Safety 2.1. Safety pictograms definition CAUTION WARNING   Warns of a risk of minor injury or Warns against serious personal injury major material damage to the device and damage to health. or environment.
  • Page 11: Hazards

    Installer Manual Evolio 255 - Safety NOTE  Ensure that the serial label and the safety tags on the device are completely legible and clean. If necessary, replace them with new tags and put them in the same places. 2.3.
  • Page 12: Hygiene And Sanitization

    Installer Manual Evolio 255 - Safety 2.4. Hygiene and sanitization 2.4.1. Sanitary issues Preliminary checks and storage • Check that the brine tank and the brine well are clean and free from burr, debris or any scraps; • check the integrity of the packaging. Check that there is no damage and no signs of contact with liquid to make sure that no external contamination occurred;...
  • Page 13 Installer Manual Evolio 255 - Safety Disinfection • The materials used for the construction of our products meet the standards for use with potable water; the manufacturing processes are also geared to preserving these criteria. However, the process of production, distribution, assembly and installation, may create conditions of bacterial proliferation, which may lead to odour problems and water contamination;...
  • Page 14: Description

    Installer Manual Evolio 255 - Description Description 3.1. Introduction to softeners 3.1.1. Softening principles Softening is an ion exchange process where the hard ions are getting exchange by soft ions, typically sodium or potassium. This is achieved by placing the water in contact with an ion exchange resin and ensuring the contact time is appropriate for the flow rate to produce.
  • Page 15 Installer Manual Evolio 255 - Description The service and regeneration reaction can be done over and over, so softening systems last years. A softener consists of different components: • a tank, filled with softening resin; • a valve, that will direct the inlet water flow on the resin bed so that the softening or regeneration reaction can take place;...
  • Page 16: System Service & Regeneration Cycles (7-Cycles Operation)

    Installer Manual Evolio 255 - Description 3.1.2. System service & regeneration cycles (7-cycles operation) Service — cycle C0 Untreated water is directed down through the resin bed and up through the riser tube. The hardness ions attach themselves to the resin and are removed from the raw water being exchanged on the resin beads towards sodium ions.
  • Page 17 Installer Manual Evolio 255 - Description SERVICE BACKWASH BRINE DRAW/SLOW RINSE C1 and C6 C2-C3 REPRESSURIZE RAPID RINSE BRINE REFILL C5 and C7 Soft water Hard water Inlet Valve Brine tank Outlet Drain Media bead Air check Media tank Brine Ref.
  • Page 18: Technical Specifications

    Installer Manual Evolio 255 - Description 3.2. Technical specifications 3.2.1. General Drain Inlet Outlet Overflow Softener type Evolio............255 10L .....255 15L.....255 20L .... 255 30L Design specifications/ratings Softener cabinet ........ABS ® Tank body..........Dowex HCRS-s resin ® Valve body ..........Glass-filled Noryl - NSF listed material Rubber components .......
  • Page 19 Installer Manual Evolio 255 - Description Nominal (residual hardness 0°f) .... 0.6 m /h... 0.9 m /h....1.2 m /h ... 1.8 m Nominal (residual hardness 5-10°f) ..0.7 m /h... 1.1 m /h....1.4 m /h ... 2.2 m Peak (residual hardness 5-10°f) .... 1.0 m /h...
  • Page 20: Outline Drawing

    Pollution Degree........3 Temporary overvoltages must be limited in duration and in frequency. 3.3. Outline drawing Evolio 255 10L model Evolio 255 all models Evolio 255 15, 20 and 30L models 20 / 90 Ref. MKT-IM-037 / B - 17.12.2018...
  • Page 21: Description And Components Location

    Installer Manual Evolio 255 - Description 3.4. Description and components location Injector and cap Turbine manifold Brine tank tube connection Air check BLFC/Refill controller Injector screen LCD display Locking bar Regeneration Optical sensor Up arrow Valve discs/flappers Down arrow Camshaft...
  • Page 22: Softener's Available Options

    3.5.1. Chlorine generator and check salt led The Evolio 255 controller has the capability to produce a low level of chlorine to chlorinate the resin bed during regeneration. A check salt light will indicate when the user needs to add salt to the brine tank.
  • Page 23: Safety Brine Valve

    Installer Manual Evolio 255 - Description 3.5.2. Safety brine valve To avoid overflow and to get a better softener operation, a safety brine valve can be installed. Operation Remove the softener covers, see 8.5.2. Covers removal (softener and valve), page 63.
  • Page 24: Installation

    Installer Manual Evolio 255 - Installation Installation 4.1. Warnings CAUTION  Do not lay down or flip over the softener at any time. The media may paste to the upper distributor thus obstructing its slots and may therefore compromise the softener operation.
  • Page 25: Electrical

    Installer Manual Evolio 255 - Installation MANDATORY  Do not exceed a maximum of 8.6 bar inlet pressure. Should this happen or be subject to happen, it is necessary to install a pressure regulator upstream the system. 4.3.3. Electrical There are no user-serviceable parts in the AC transformer, motor, or controller. In the event of a failure, these should be replaced.
  • Page 26: Mechanical

    Installer Manual Evolio 255 - Installation 4.3.4. Mechanical CAUTION  Do not over-tighten the pipe to piping boss. CAUTION  Do not put excessive force on the inlet, outlet or drain connections of the valve. • Do not use petroleum-based lubricants such as vaseline, oils, or hydrocarbon-based lubricants.
  • Page 27: Softener Connection To Piping

    4.5. Softener connection to piping  To prevent your softener from incoming sediment and iron particles, Pentair recommends the installation of a 100 μm pre-filter upstream the unit. MANDATORY ...
  • Page 28: Installation Layout

    Installer Manual Evolio 255 - Installation 4.5.2. Installation layout Softener Power supply Soft water pipe Hard water pipe ½" overflow line Drain 4.5.3. Tools and material required for installation NOTE  Not all listed tools may be necessary for installation. Read installation procedures before starting to determine if additional tools are necessary.
  • Page 29: Inspection/Preliminary Assembly

    Installer Manual Evolio 255 - Installation Materials: • softener; • pipes; ® • Teflon tape; • grounding straps (optional); • overflow pipe ½"; • valve drain pipe ½". Material included: • by-pass. 4.5.4. Inspection/preliminary assembly 4.5.4.1 Inspection MANDATORY  Any missing or faulty equipment must be specified on the transport documents. Notify the transporter company and supplier immediately.
  • Page 30 Installer Manual Evolio 255 - Installation Make necessary piping changes for connecting the softener inlet and outlet to the home piping. Make sure not to reverse inlet and outlet. Installation of supplied bypass is highly recommended, see 4.5.6.2 Bypassing, page 32.
  • Page 31: Water Supply Line And Bypass Connections

    Installer Manual Evolio 255 - Installation 4.5.6. Water supply line and bypass connections 4.5.6.1 Water supply line The connections should be hand tightened using PTFE (plumber’s tape) on the threads if using the threaded connection type. In case of heat welding (metal type connection), the connections should not be made to the valve when soldering.
  • Page 32 4.5.6.2 Bypassing A bypass valve system can be installed on all Evolio 255 softening systems. Bypass valves isolate the softener from main water line and allow unconditioned water to be used. Service or routine maintenance procedures may also require that the system is bypassed.
  • Page 33: Drain Line Connection

    Installer Manual Evolio 255 - Installation Normal operation In Bypass  CAUTION  Do not solder pipes with lead-based solder. CAUTION  Do not use tools to tighten plastic fittings. Over time, stress may break the connections. When the 256 bypass valve is used, only hand tighten the plastic nuts.
  • Page 34 Installer Manual Evolio 255 - Installation Where the drain line is elevated but empties into a drain below the level of the valve, form a 18 cm loop at the far end of the line so that the bottom of the loop is level with the drain line connection. This will provide an adequate siphon trap.
  • Page 35: Overflow Line Connection

    Installer Manual Evolio 255 - Installation 4.5.8. Overflow line connection In the event of a malfunction, the brine tank overflow fitting will direct “overflow” to the drain instead of spilling on the floor. This fitting should be at the back of the cabinet.
  • Page 36: Electrical Connection

    Installer Manual Evolio 255 - Installation 4.5.9. Electrical connection 4.5.9.1 Softener connection Power supply 4.5.9.2 Meter connection NOTE  During shipping, the cable from the back of the controller to the meter assembly may have been disconnected. If it has, insert the end of the cable into the top of the meter assembly (1).
  • Page 37 Installer Manual Evolio 255 - Installation 4.5.9.3 Evolio 255 controller connection Chlorine generator connection AC transformer input (low voltage) Main motor & optical sensor connection Sensor input for turbine Ref. MKT-IM-037 / B - 17.12.2018 37 / 90...
  • Page 38: Programming

    Installer Manual Evolio 255 - Programming Programming NOTE  Menus are displayed in a defined and incremental order. 5.1. Display time/day regeneration time salt amount capacity hardness 1. Hourglass Displayed when the motor is running. The camshaft should be turning.
  • Page 39 Installer Manual Evolio 255 - Programming 7. "PM" Indicates that the time displayed is between 12:00 noon and 12:00 midnight. "PM" indicator is not used if the clock mode is set to 24-hour (there is no PM indicator). 8. "MIN"...
  • Page 40: Commands

    Installer Manual Evolio 255 - Programming 5.2. Commands time/day regeneration time salt amount capacity hardness check salt 1. Display Used to show informations, see 5.1. Display, page 38. 2. LED Warning for low salt level (if chlorine generator is installed).
  • Page 41: Quick Program Guide

    Installer Manual Evolio 255 - Programming 5.3. Quick program guide Value to enter for model Initial Press Range Parameter Evolio 255 Evolio 255 display UP and DOWN arrow to scroll through Volume of 5 - 80 values, press SET to confirm.
  • Page 42 Installer Manual Evolio 255 - Programming Value to enter for model Initial Press Range Parameter Evolio 255 Evolio 255 display UP and DOWN arrow to scroll through Volume of 5 - 80 values, press SET to confirm. resin in L...
  • Page 43: Basic Programming

    Installer Manual Evolio 255 - Programming 5.4. Basic programming 5.4.1. Program system size Set the resin volume in liters. to scroll though resin volume choices. Choose the volume to your system model (10, 15, 20 or 30 L). Press to validate the resin volume selected and advance to the next parameter using If an incorrect setting is programmed, see “Resetting the...
  • Page 44: Regeneration Time

    Installer Manual Evolio 255 - Programming 5.4.4. Regeneration time Set the time at which regeneration will take place. Press → Regeneration time flashes. Adjust displayed time with Default setting: 2:00am. Press to validate the selection and advance to the next parameter using 5.4.5.
  • Page 45: Estimated Capacity

    Installer Manual Evolio 255 - Programming 5.4.7. Estimated capacity NOTE  The system capacity is displayed in kilograms equivalent CaCO of hardness removed before a regeneration is necessary when programmed in metric units mode. NOTE  Value is derived from the system’s resin volume input and salt amount input and must be fine tuned for optimal operation.
  • Page 46: Hardness

    5 seconds to access advance programming. A "P" symbol is displayed on the bottom left of screen. The Evolio 255 features an advanced programming level that allows the installer to make changes to the controller for more demanding applications. The homeowner/end user should never have to access this level.
  • Page 47: Regeneration Cycles Time

    Installer Manual Evolio 255 - Programming • P8 = Hardness; • P9** = Units of measurement; • P10** = Clock mode. * Calculated by software, modifiable to fine tune softener operation. ** Pre-selected by World model (i.e. 220-230 VAC, 50 Hz, metrics unit).
  • Page 48: History Value

    Installer Manual Evolio 255 - Programming Salt Cycle Evolio 255 10L Evolio 255 15L Evolio 255 20L Evolio 255 30L setting 17 min 22 min 25 min 25 min C2 + C3 44 min 65 min 72 min 71 min...
  • Page 49: Resetting The Controller

    Installer Manual Evolio 255 - Programming Diagnostic Description Unit Range Code Average usage for Tuesday 0 - 6553.6 Average usage for Wednesday 0 - 6553.6 Average usage for Thursday 0 - 6553.6 Average usage for Friday 0 - 6553.6 Average usage for Saturday 0 - 6553.6...
  • Page 50: Commissioning

    Installer Manual Evolio 255 - Commissioning Commissioning 6.1. Softener commissioning 6.1.1. Water filling, draining and waterproofness inspection Once the previous initial programming steps are performed, and that the softener is in place and hydraulically connected to the main water line (see 4.5.5. Softener installation, page 29), the unit can be started up.
  • Page 51: Quick Cycling

    Installer Manual Evolio 255 - Commissioning → Unplug the power transformer from the socket so that the valve remains in backwash position. → When most of the air has been purged from the media tank (water begins to flow steadily from the drain line), open the main supply valve all of the way.
  • Page 52: Startup

    (1) setting iteratively until the residual hardness correspond to the value used when programming the hardness parameter. NOTE  Pentair advise to set a residual hardness between 50 and 100 mg/L of CaC0 52 / 90 Ref. MKT-IM-037 / B - 17.12.2018...
  • Page 53: Additional Tips

    Installer Manual Evolio 255 - Commissioning 6.1.4. Additional tips • When the controller is first plugged in, it may display a flashing hourglass and the message "Err 3", this means that the controller is rotating to the home position. If the "Err 2" is displayed, check that the incoming power frequency matches the controller;...
  • Page 54: Sanitization By Electrochlorination Process

    Installer Manual Evolio 255 - Commissioning 6.2.2.1 5.25% Sodium hypochlorite If stronger solutions are used, such as those sold for commercial laundries, adjust the dosage accordingly. Dosage Polystyrene resin: set 1.25 mL per liter of resin. Brine tank softeners Backwash the softener and add the required amount of hypochlorite solution to the well of the brine tank.
  • Page 55: Operation

    Installer Manual Evolio 255 - Operation Operation 7.1. Display 7.1.1. During operation Depending of the clock mode programmed, display shows: • P10=0, current time in 12 am/pm alternating with remaining capacity in US gallons; • P10=1, current time in 24 hours alternating with remaining capacity in cubic meters.
  • Page 56: Manual Regeneration

    Installer Manual Evolio 255 - Operation 7.2. Manual regeneration MANDATORY  The controller must be in service in order to enable this procedure. NOTE  The unit returns to normal operation if no buttons are pressed within 30 seconds. 7.2.1. Manual delayed regeneration Press once for delayed regeneration.
  • Page 57: Second Delayed Regeneration

    Installer Manual Evolio 255 - Operation 7.2.5. Second delayed regeneration When a regeneration is already on going, press once for a second delayed regeneration to be planned. → A "x2" icon will be flashing on the screen. 7.2.6. Second immediate regeneration...
  • Page 58: Maintenance

    Installer Manual Evolio 255 - Maintenance Maintenance MANDATORY  Cleaning and maintenance shall take place at regular intervals in order to guarantee the proper functioning of the complete system, and be documented in the Maintenance chapter in the User Guide document.
  • Page 59: Regeneration Test

    Installer Manual Evolio 255 - Maintenance 8.1.3. Regeneration test 1. Check condition of brine tank and any associated equipment. 2. Check salt level in brine tank. 3. Initiate regeneration test. → Check brine draw during brine draw stage, observe aircheck ball and make sure of proper function.
  • Page 60: Maintenance Instructions

    Installer Manual Evolio 255 - Maintenance Items 1 year 2 year 3 year 4 year 5 year Optical sensor Check Check Check Check Replace Inlet hardness Check Check Check Check Check Check/adapt Check/adapt Check/adapt Check/adapt Check/adapt Residual mixing screw if...
  • Page 61: Adding Salt

    8.3. Adding salt  Scan this QR code to download the Salt Reminder application from Pentair in order to ensure refilling the salt in the brine tank when required.  Do no fill the brine tank with too much salt if you are approaching to brine tank cleaning date.
  • Page 62: Recommendations

    Installer Manual Evolio 255 - Maintenance 8.4. Recommendations 8.4.1. Use original spare parts CAUTION  To ensure correct operation and safety of the device, only use original spare parts and accessories recommended by the manufacturer. Parts to keep in stock for potential replacements are motor and optical sensor, controller, transformer, injectors, flapper kit, o-ring kit, refill controller and DLFC.
  • Page 63: Covers Removal (Softener And Valve)

    Unlock the valve cover (3) from the slide clips (4) (one on each side of the valve). Remove the valve cover (3). Reverse above procedure steps to rebuild. See 4.5.9.3 Evolio 255 controller connection, page 37. Ref. MKT-IM-037 / B - 17.12.2018...
  • Page 64: Brine Tank And Brine Well Cleaning

    Refit the brine tank cover (5). Refit the softener cover (2). Acceding from behind the softener, connect the controller (1), see 4.5.9.3 Evolio 255 controller connection, page 37. Fill the brine tank (8) with salt, see 8.3. Adding salt, page 61.
  • Page 65 Installer Manual Evolio 255 - Maintenance Ref. MKT-IM-037 / B - 17.12.2018 65 / 90...
  • Page 66: Cleaning The Injector Screen

    Installer Manual Evolio 255 - Maintenance 8.5.4. Cleaning the injector screen Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Using a Torx key, unscrew and extract the injector screen cap (1) on which the injector screen (2) is clipped.
  • Page 67: Cleaning The Injector

    Installer Manual Evolio 255 - Maintenance 8.5.5. Cleaning the injector Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Using a Torx key, unscrew and remove the injector cap (1). CAUTION  Take care not to damage the injector (2)....
  • Page 68: Controller Replacement

    Installer Manual Evolio 255 - Maintenance 8.5.6. Controller replacement Operation CAUTION  Do not pull on the cables. Release the connectors from controller (3) by pressing on their locking clips. Acceding from behind the softener, disconnect the controller (3). Remove the softener cover (1).
  • Page 69: Other Wear And Tear Parts

    Installer Manual Evolio 255 - Maintenance 8.5.7. Other wear and tear parts 8.5.7.1 Cleaning the air check valve Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Dismount the brine hose (5). Using a Phillips screwdriver, loosen air check cap screw (2) (2x).
  • Page 70 Installer Manual Evolio 255 - Maintenance 8.5.7.2 Cleaning DLFC Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Using a Torx key, unscrew and extract DLFC (3). Clean DLFC (3) using a soft brush or compressed air.
  • Page 71 Installer Manual Evolio 255 - Maintenance 8.5.7.3 Cleaning the refill controller Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Using a Torx key, unscrew and extract the refill controller (3). Clean the refill controller (3) with a soft brush....
  • Page 72 Installer Manual Evolio 255 - Maintenance 8.5.7.4 Motor and camshaft replacement Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Disconnect the motor (4) from the optical sensor (1). Remove the white locking pin (3) securing the motor (4).
  • Page 73 Installer Manual Evolio 255 - Maintenance Ref. MKT-IM-037 / B - 17.12.2018 73 / 90...
  • Page 74 Installer Manual Evolio 255 - Maintenance 8.5.7.5 Top plate and disc valve/flappers replacement Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Remove the motor and camshaft, see 8.5.7.7 Optical sensor replacement, page 77.
  • Page 75 Installer Manual Evolio 255 - Maintenance Ref. MKT-IM-037 / B - 17.12.2018 75 / 90...
  • Page 76 Installer Manual Evolio 255 - Maintenance 8.5.7.6 Disassembling valve from tank Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Using a Phillips screwdriver unscrew the screw (5) from the locking bar (4), so that the locking bar (4) can be slid out of its position.
  • Page 77 Installer Manual Evolio 255 - Maintenance 8.5.7.7 Optical sensor replacement Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. NOTE  To remove the optical sensor, first disassemble the camshaft and motor. See “Motor and camshaft replacement”, page 72.
  • Page 78: Troubleshooting

    Installer Manual Evolio 255 - Troubleshooting Troubleshooting 9.1. Controller Issue Cause Reset and recovery Controller power has been connected Reset controller. ERR 1 and the controller is not sure of the See 5.5.3. Resetting the controller, operating status. page 49.
  • Page 79: Valve

    Installer Manual Evolio 255 - Troubleshooting Issue Cause Reset and recovery If motor keeps rotating indefinitely, replace the following components in this order: • wire harness; Camshaft rotates for more than 5 • motor; ERR3 minutes to find Home position.
  • Page 80: System

    Installer Manual Evolio 255 - Troubleshooting Issue Cause Reset and recovery Set pump or pressure regulator to Intermittent or Low water pressure. maintain 1.38 bar (20 psi) dynamic at irregular brine softener’s inlet. draw. Defective injector. Replace injector. Backwashes or Incorrect drain control used.
  • Page 81 Installer Manual Evolio 255 - Troubleshooting Issue Cause Reset and recovery Control brine dosage set and repeat Improper regeneration. regeneration. Set P6 to proper level. Incorrect brine setting. See 5.4.6. Salt setting, page 44. Run out of Incorrect hardness or capacity Set to correct values.
  • Page 82: Spare Parts

    Installer Manual Evolio 255 - Spare parts Spare parts 10.1. Softener 82 / 90 Ref. MKT-IM-037 / B - 17.12.2018...
  • Page 83 3/8" brine tubing, roll of 30m CABCOVEVW Softener cover all Evolio 255 models CABHINGEV Hinge CABCOVLIDVW Salt lid with stainless steel hinge CABCOVEVWH255 Softener cover all Evolio 255 models with controller LB-255-EV Controller label CABFPEV255860 Controller plate 400879 Salt lid bumpers DPEX818S...
  • Page 84: Valve

    Installer Manual Evolio 255 - Spare parts 10.2. Valve 10.2.1. Valve body parts list Packaging Item Part number Description quantity 1267672 Cover Euro Slimline 1235353 Cam 255/700-860 series valve, STD, black Motor with spacer pinion, cable, 700 series controller, 1238861...
  • Page 85 Installer Manual Evolio 255 - Spare parts Packaging Item Part number Description quantity Injector (high efficiency) Options 1035730 “E” Injector (high efficiency) - yellow Evolio 10L model 1035731 “F” Injector (high efficiency) - peach Evolio 15L model 1035732 “G” Injector (high efficiency) - tan Evolio 20L model “H”...
  • Page 86: Evolio 255 Controller

    Installer Manual Evolio 255 - Spare parts 10.2.2. Evolio 255 controller Packaging Item Part number Description quantity 62093 Controller Transformer 1000813 British 1000814 European 1030234 Transformer extension cord 4.5 m (15 ft) 10.2.3. Meters Packaging Item Part number Description quantity...
  • Page 87: Piping

    Installer Manual Evolio 255 - Spare parts 10.3. Piping 10.3.1. Bypass & connections Packaging Item Part number Description quantity 1040769 Bypass body assy (includes bypass installation kit) 1040524 Bypass installation kit 1034302 Bypass repair kit (rotor seals & clips) 3028264...
  • Page 88: Disposal

    This will help to reduce the impact on the environment, health, safety and help to promote recycling. Pentair does not collect used product for recycling. Contact your local recycling center for more information.
