EVERPURE
ENDURANCE™ HIGH FLOW WATER FILTER SYSTEM
®
Twin System
INTRODUCTION
The Everpure Endurance™ High Flow water filter system is designed to treat up to 200,000 gallons of water per year. The
system uses a pretreatment filter, 2, 3 or 4 fine cartridges and a scale inhibiting cartridge.
INSPECTION
Before mounting the Endurance system, inspect the parts. Use the table and illustration to verify the parts and quantities. If
any parts are missing, contact Customer Service at 630.307.3000 or by email at CSeverpure@pentair.com.
Parts
1. Manifold with Bracket
2. Shroud
3. Pleated Endurance HF Cartridge
4. Pretreatment Housing
5. Housing Wrench
6. 2SR-BW Cartridge
7. SEN Cartridge
8. Port Plug
SELECTING A LOCATION
The location selected for system installation should allow for:
Adequate space for "in" and "out" water line connections.
Mounting screws should anchor into a solid structure.
The frame is designed to mount on 16 inch centers (wall studs).
Allow 5 inches below the cartridges for removal.
The pretreatment housing can be removed from the frame and mounted seperately. Be certain to use adequate lengths
of opaque beverage tubing.
Give consideration to the weight of the system when filled with water. Operating weights of the Endurance system are:
High Flow Twin System - 58.4 lbs. (26.5 kg)
High Flow Triple System - 63.8 lbs. (28.9 kg)
High Flow Quad System - 69.1 lbs. (31.3 kg)
WATER SOLUTIONS
Twin
Triple
Quad
1
1
1
1
1
1
1
1
1
1
1
1
2
3
2
1
INSTRUCTION AND OPERATION GUIDE
Triple System
1
1
1
1
1
1
1
3
4
0
Quad System
5
6
4
2
7
8
