5.2. Electrical Installation

5.2.1. Cables General
NB!
Cables General
Always comply with national and local regulations on cable cross-sections.
Details of terminal tightening torques.
Power (kW)
Enclo- 200-240
sure V
0.25 -
A2
3.0
A3 3.7
0.25 -
A5
3.7
B1 5.5 -11
B2 - 15
C1 18.5 - 30
C2 37 - 45
D1/D3 -
D2/D4 -
E1/E2 -
Table 5.2: Tightening of terminals.
5.2.2. Removal of Knockouts for Extra Cables
1. Remove cable entry from the frequency converter (Avoiding foreign parts falling into the frequency converter when removing knockouts)
2. Cable entry has to be supported around the knockout you intend to remove.
3. The knockout can now be removed with a strong mandrel and a hammer.
4. Remove burrs from the hole.
5. Mount Cable entry on frequency converter.
5.2.3. Gland/Conduit Entry - IP21 (NEMA 1) and IP54 (NEMA12)
Cables are connected through the gland plate from the bottom. Remove the plate and plan where to place the entry for the glands or conduits. Prepare
holes in the marked area on the drawing.
The gland plate must be fitted to the frequency converter to ensure the specified protection degree, as well as ensuring proper cooling of the unit. If the
gland plate is not mounted, it may trip the unit.
380-480 525-690
Line
V V
0.37 -
1.1 - 4.0 1.8
4.0
5.5 - 7.5 5.5 - 7.5 1.8
0.37 -
1.1 - 7.5 1.8
7.5
11 - 18 - 1.8
22 - 2.5
30 - 4.5
37 - 55 - 10
75 - 14
90 - 24
110 110 19
132 132 19
160-250 160-315 19
315-450 355-560 19
®
