Danfoss VLT AQUA Drive Design Manual page 60

3. VLT AQUA Selection
FC 202, P37KT2
Cable
length [m]
30
100
150
3
FC 202, P45KT2
Cable
length [m]
30
100
150
FC 202, P1K5T4
Cable
length [m]
5
50
150
FC 202, P4K0T4
Cable
length [m]
5
50
150
FC 202, P7K5T4
Cable
length [m]
5
50
150
FC 202, P11KT4
Cable
length [m]
15
100
150
FC 202, P15KT4
Cable
length [m]
36
100
150
60
Mains Rise time
voltage [V] [μsec]
240 0.300
240 0.536
240 0.776
Mains Rise time
voltage [V] [μsec]
240 0.300
240 0.536
240 0.776
Mains Rise time
voltage [V] [μsec]
690 0.640
985 0.470
1045 0.760
Mains Rise time
voltage [V] [μsec]
400 0.172
400 0.310
400 0.370
Mains Rise time
voltage [V] [μsec]
500 0.04755
500 0.207
500 0.6742
Mains Rise time
voltage [V] [μsec]
480 0.192
480 0.612
480 0.512
Mains Rise time
voltage [V] [μsec]
480 0.396
480 0.844
480 0.696
MG.20.N4.02 - VLT
Vpeak
[kV]
0.598
0.566
0.546
Vpeak
[kV]
0.598
0.566
0.546
Vpeak
[kV]
0.690
1.045
Vpeak
[kV]
0.890
1.190
Vpeak
[kV]
0.739
1.030
Vpeak
[kV]
1.300
1.300
1.290
Vpeak
[kV]
1.210
1.230
1.160
®
is a registered Danfoss trademark
®
VLT AQUA Drive Design Guide
dU/dt
[kV/μsec]
1.594
0.844
0.562
dU/dt
[kV/μsec]
1.594
0.844
0.562
dU/dt
[kV/μsec]
0.862
0.985
0.947
dU/dt
[kV/μsec]
4.156
2.564
1.770
dU/dt
[kV/μsec]
8.035
4.548
2.828
dU/dt
[kV/μsec]
5.416
1.699
2.015
dU/dt
[kV/μsec]
2.444
1.165
1.333
