Agrowtek GrowControl GC-Pro Operation Manual page 17

Thermostat Settings
Each thermostat has specific settings which control its function.
Zone # Temperature Source
(0 defaults to 1) (Air, Water or Outdoor)
Zone#: The zone that the thermostat will take sensor readings from.
Temperature Source: The sensor type from the selected zone (air temperature, water temperature or outdoor temperature.)
Day/Night Set Points: Temperature values for the day and night which will activate the thermostat.
Dead-band: Temperature drop from set-point before turning on heat or turning off cooling (see dead-band below.)
Output#: Enter an output number to turn on (or off if limit control) when the thermostat is active.
VSC#: Enter a VSC channel # to send the target positions to when the thermostat is active.
Dead-Band
The "Deadband" setting in determines how tightly a thermostat tries to keep the temperature to the set-point. It is necessary
to have some dead-band: generally 2.0-5.0°F or 1.0 – 3.0°C.
Set Point
On
Output
Off
Touch Panel
Press "Temp" from the controls menu.
www.agrowtek.com
Day & Night Values
Output #
Turn On/Off
Heating
Dead
Band
© 2013 Agrowtek Inc.
| 83 Ambrogio Dr Suite H Gurnee, IL 60031 | agrowtek@agrowtek.com
Set-Points Dead Band
Hysteresis Setting
Thermostat Control
VSC Channel
Send position to channel
Set Point
On
Output
Off
Select cooling, heating or high/low limit
functions.
Output #
To turn on/off
Use standard on/off output, VSC output,
or both simultaneously when thermostat
control is activated.
Cooling
Dead
Band
VSC Set-Points
Channel & Position
(if using VSC)
16
