The FA-M3 R supports remote equipment maintenance, called "Remote OME. "
Remote OME is achieved:
(1) Over a local area network via Ethernet, whereby OME requests are connected using a readily
available dial-up router to a public phone line
(2) Over public phone lines via a modem connected to the Programming port
For an FA-M3 R incorporated in a system, the following can be done from a personal computer at a distant
place:
• Machine maintenance and inspections using the device monitoring and diagnostics functions
• Check of machine operating statuses by monitoring the FA-M3 R's devices online, and machine
operation test by changing the device values
• Troubleshooting and failure analyses for machine using the FA-M3 R's diagnostics functions, namely,
such as to the error log, user log and sampling traces
• Improvement of machine operation by adding, modifying and debugging a ladder diagram.
There are two methods of remote OME:
• Via Ethernet ( remote maintenance camera is available)
• Via public telephone lines
TI 34M6A01-01E

Remote OME

Remote OME involves performing the following remotely:
Operation: Operation and monitoring
Maintenance: Troubleshooting
Engineering: Program modification and debugging
