YOKOGAWA UT Series Instruction Manual

External device connection manual for TOP Design Studio
YOKOGAWA Electric Corporation
Supported version TOP Design Studio
CONTENTS
We want to thank our customers who use the Touch Operation Panel.
1.
System configuration
Describes the devices required for connection, the setting of
each device, cables, and configurable systems.
2.
External device selection
Select a TOP model and an external device.
3.
TOP communication setting
Describes how to set the TOP communication.
4.
External device setting
Describes how to set up communication for external devices.
5.
Cable table
Describes the cable specifications required for connection.
6.
Supported addresses
Refer to this section to check the addresses which can
communicate with an external device.
UT/UP/UM Series
PC Link Driver
V1.4.3.0 or higher
Page 2
Page 3
Page 4
Page 9
Page 11
Page 14
