Introduction
1 LCP (local control panel)
2 RS485 serial bus connector
3 Digital I/O and 24 V power supply
4 Analog I/O connector
5 USB connector
6 Serial bus terminal switch
7 Analog switches (A53), (A54)
8 Relay 1 (01, 02, 03)
Figure 1.2 Close-up View: LCP and Control Functions
NOTICE!
For location of TB6 (terminal block for contactor), see
chapter 4.6 Motor Connection.
1.4.3 Extended Options Cabinets
If an adjustable frequency drive is ordered with one of the
following options, it is supplied with an options cabinet
that makes it taller.
•
Brake chopper
•
Line power disconnect
•
Contactor
MG34U422
Instruction Manual
1
6
7
2
5
3
9
10 Lifting ring
11 Mounting holes
12 Cable clamp (PE)
13 Ground
14 Motor output terminals 96 (U), 97 (V), 98 (W)
15 Line power input terminals 91 (L1), 92 (L2), 93 (L3)
16 TB5 (IP21/54 only). Terminal block for anti-condensation heater
Danfoss A/S © 06/2015 All rights reserved.
10
11
4
8
9
Relay 2 (04, 05, 06)
•
Line power disconnect with contactor
•
Circuit breaker
•
Oversized wiring cabinet
•
Regeneration terminals
•
Load share terminals
Figure 1.3 shows an example of an adjustable frequency
drive with an options cabinet. Table 1.2 lists the variants for
the adjustable frequency drives that include input options.
1 1
