Sime MURELLE REVOLUTION 30 User, Installation And Servicing Instructions page 83

Pos. Code Description
129 6226638 Divertor valve motor spring cli
130 6319644 Flowmeter group
131 6319645 Three-way plates group
132 6013182 Automatic air vent
134 6248847 Gasket Ø 160
135 6248823 OR gasket Ø80
137 6226464 O-ring 115 diam. 11,91x2,62
138 6248855 P.C. inlet/oulet smokes gasket
140 6175180 Flow control spacer
141 6281431 14 l/min. flow control
142 6275911 Pressure relief valve operation
143 6177530 Gas cock 3/4" F x 15
144 6177523 Ball cock 3/4"
145 6177506 Ball cock 1/2" x 15
146 6142330 Quarter bend 1/2" x 15
150 6326860 PDC battery fumes + insulation
151 6261419 PDC fan
152 6326885 PDC air battery
153 6265675 PDC plate-type heat exchanger
154 6326882 PDC compressor
155 6326887 PDC regulator
156 6326884 Expansion valve
157 6326883 PDC receiver
158 6247720 Funnel water trap
159 6326888 PDC capacitor
160 6326889 PDC sight glass
161 6326890 PDC liquid filter
162 6326891 PDC coat/insulating
163 6087561 Antivibration compressor
164 6326892 High pressure switch
165 6326893 Low pressure switch
166 6240709 Power supply 24VDC DIN
167 6326896 Fuse holder
168 6326895 Magnetothermal switch C10/1N
169 6326894 Valve electrical coil
170 6326897 NTC probe -50 +105°C
700 8092287 Remote control
701 8094101 External sensor
702 6319700 Springs / clamps kit DIN
703 6281534 Gaskets kit
704 6319695 Murelle-Format-.....o-ring kit
705 6211794 Peephole kit
706 5202555 Complete control panel
708 6323875 6 pole cable connector CN12
709 6323876 4 pole cable connector CN14
710 6325628 14 pole cable connect.CN15+CN5
711 6325659 9 pole cable connector CN1
712 6325658 6 pole cable connector CN2
713 6326898 Fuse 5x20 0,8 AF
714 6326899 Fuse 5x20 2 AF
715 5184817 Fitting cocks kit
716 8092286 Remote control
