7.5

Circuit Board Replacement

Should the circuit board be replace, the engineer MUST set
the parameters as indicated in this table and in the sequence
shown.
Type No. Description
Index showing boiler power in kW
PAR 01 5 = 25 (MURELLE REVOLUTION 25)
6 = 30 (MURELLE REVOLUTION 30)
Hydraulic configuration
0 = combi
1 = system
PAR 02
2 = N/A
3 = N/A
4=instant with solar power input
Gas Type Configuration
PAR 03
0 = G20/G25; 1 = G31
To enter "Parameter setting and display"refer to the indica-
tions provided in the specific section.
Once the parameters in the table have been set, you must carry
out the entire phase of "Self-calibrating procedure" described
in the specific section.
If the gas valve and/or the ignition/detection electrode , and/or
the burner , and/or the fan are replaced, the engineer must still
carry out the entire phase of "Self-calibrating procedure" de-
scribed in the specific section.
7.6

Malfunction codes and possible solutions

Boiler fault (gas side)
Type No. Fault
ALL 01 Not used
Low water pres-
ALL 02
sure in system
High water pres-
ALL 03
sure in system
Domestic hot
ALL 04 water sensor (SS)
fault
Delivery sensor
ALL 05
(SM) fault
ALL 06 No flame detection
Safety thermostat
ALL 07
(TS), intervention
Fault in the flame
ALL 08
detection circuit
No water circulat-
ALL 09
ing in the system
Auxiliary sensor
ALL 10
fault
70
Setting for Murelle
Revolution 30
6
0
0 or 1
Solution
-
- Restore pressure
- Check for any leaks in the
system
- Empty the system via the drain
valve on the hydraulic assembly
and bring the pressure to
approximately 1.2 bar
- Check connections
- Check the sensor is working
- Check connections
- Check the sensor is working
- Check the integrity of the
electrode and check that it is
not grounded
- Check gas availability and
pressure
- Check the operation of the gas
valve
- Check the sensor or thermo-
stat connections
- Deaerate the system
- Check the bleed valve
- Replace the sensor or the
thermostat
- Check that the pump impeller
is not blocked
- Check the integrity of the
electrode and check that it is
not grounded
- Check gas availability and
pressure
- Check the operation of the gas
valve
- Check the rotation of the pump
rotor
- Check the electrical connec-
tions
- Replace the pump
- Check PAR 02 "hydraulic con-
figuration"
- Check the electrical connection
Type No. Fault
Gas valve modula-
ALL 11
tor disconnected
Incorrect configu-
ALL 12 ration of the open
/ sealed chamber
Exhaust sensor
ALL 13
(SF) intervention
Exhaust sensor
ALL 14
(SF) fault
Fan check cable
ALL 15
disconnected
Condensate level
ALL 18
fault
Maximum number
ALL 28 of consecutive
resets reached (6)
Return sensor
ALL 30
(SR) fault
Fault due to low
ALL 37
network voltage
Incorrect supply
ALL 40 frequency de-
tected
Flame loss more
ALL 41 than 6 consecutive
times
ALL 42 Button fault
Open Therm com-
ALL 43
munication fault
Gas valve timeout
ALL 44
fault without flame
Self-calibrating
ALL 62 procedure is
required
Incorrect position-
ALL 72 ing of the delivery
sensor
EV2 SGV current
ALL 77 max/min absolute
limits error
EV2 SGV current
ALL 78
upper limit error
EV2 SGV current
ALL 79
lower limit error
Fault on the valve
control logic line/
ALL 80
valve cable dam-
aged
Block due to
numerous com-
ALL 82
bustion control
failures
Flow rate reduced
for (presumed) low
ALL 84
pressure on mains
gas
Internal error
ALL 88 (board component
protection)
Solution
- Check the electrical connection
- Set the parameter PAR 04
(Combustion configuration) to 0
- Replace the smoke probe
- Contact the Technical Assis-
tance Centre
- Replace the smoke probe
- Check the electrical connection
of the smoke probe, if the prob-
lem is not resolved, contact the
Assistance Centre
- Check the connection cable
between the fan and the board
- Check for any clogging in the
pipe which takes the conden-
sate to the siphon
- Check that the siphon is not
clogged
- Wait 1 hour and try unblocking
the board again
- Contact the Technical Assis-
tance Centre
- Replace the return probe
- Check parameters
- Contact the Technical Assis-
tance Centre
- Check the voltage
- Contact your network provider
- Contact your network provider
- Check the ignition/detection
electrode
- Check the gas supply (open
valve)
- Check mains gas pressure
- Check that buttons are working
- Check the OT electric connec-
tion
- Check gas valve and board
- Carry out the self-calibrating
procedure (see the specific
section)
- Check delivery sensor opera-
tion and position
- Check gas valve and board
- Check gas valve and board
- Check gas valve and board
- Check gas valve and board
- Check electrode
- Check outlets
- Check gas flow rate
- Check the board is working
- Replace board
