Main Water Circuit - Sime MURELLE REVOLUTION 30 User, Installation And Servicing Instructions

4.7

Main water circuit

36
1
4
5
7
9
20
S3
KEY:
M System flow
R System return
U Domestic hot water outlet
E Domesti hot water inlet
S Safety valve outlet
G Gas supply
S3 Condensate outlet
Primary heat exchanger
1
Domestic hot water sensor (SS)
2
Boiler fan
3
Thermal safety thermostat (TS)
4
Heating delivery probe
5
Domestic hot water heat exchanger
6
Diverter valve
7
Automatic by-pass
8
Condensate siphon outlet
9
Gas valve
10
Domestic hot water flow meter
11
Domestic hot water filter
12
Gas boiler outlet
13
System relief valve
14
Pump
15
18
3
6
8
2
10
21
M U G
29 28
25
19
16
24
15
17
13
11
12
14
23
22
E R S
Automatic bleed valve
16
Pressure transducer
17
System expansion vessel
18
HP water inlet probe
19
System flow cock
20
Gas cock
21
Domestic hot water inlet cock
22
System return cock
23
Return temperature probe
24
HP water outlet temperature probe
25
Plate heat exchanger
26
HP ON/OFF compressor
27
Expansion valve thermal bulb
28
HP high pressure switch
29
Liquid level indicator
30
Thermostatic expansion valve
31
Filter
32
Liquid receptacle
33
Air evaporator
34
HP high pressure switch
35
Smoke evaporator
36
Smoke HP by-pass solenoid valve
37
HP battery probe
38
37
35
26
38
27
30
32
31
33
34
Fig. 35
