Structure - Sime MURELLE REVOLUTION 30 User, Installation And Servicing Instructions

4.5

Structure

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Air inlet pipe
1
Gas boiler smoke evaporator
2
Heat exchanger bleed point
3
Heat exchanger
4
Exhaust sensor (SF)
5
Combustion chamber door
6
Air/gas duct
7
Flame viewing window
8
Ignition/detection electrode
9
Expansion vessel
10
Safety thermostat (TS)
11
Delivery sensor (SM)
12
33 32
19 20
Fan
13
Condensate siphon
14
Diverter valve
15
System filling unit
16
Domestic hot water sensor (SS)
17
Boiler control panel (gas side)
18
Domestic hot water heat exchanger
19
Gas valve
20
Automatic bleed valve
21
HP control panel
22
Return temperature probe
23
31
21
30
29
28
25
24
22 23
Domestic hot water filter
24
System relief valve
25
Boiler drain
26
Pump
27
Water pressure transducer
28
Plate capacitor
29
Air evaporator
30
Heat pump air outlet duct
31
Boiler smoke outlet duct
32
Boiler/heat pump air inlet duct
33
27
26
Fig. 33
