USING THE BOILER MURELLE REVOLUTION 30

1.1

Main control panel (remote)

The main control panel (MCP) allows all of the necessary adjustments to be made to Murelle Revolution 30 and to the connected
systems.
It also serves as a main room thermostat and can therefore be used by all operators, users, authorised maintenance technicians and
the technical service for the operations for which each of these figures is authorised, as described in detail in the relevant sections.
It communicates with the boiler control panel with an unpolarised bus line and OpenTherm protocol, and with the heat pump control
panel with a RS485 polarised ModBus two-wire line.
It is equipped with a volt free input for remote control, where relevant (GSM-Dialler/WiFi).
1 Button (A)
Multifunction encoder
2
3 Button (B)
Action carried out by pressing button (B)
4
5 Programmed time band
Mode selection
6
Measured outdoor temperature
7
Time
8
Presence of outdoor probe (OP)
9
1.1.1

Using the buttons

With the appliance powered, from the "Main screen" .
Zone
Menu
10
13
14
15
Zona
16
Modo: Inverno Progr. automatico - Set 18,0°C fino alle 11:30
17
Menu
1
Thu 18 Set 2014 10:30
Off
Mode
12 10 8
11 9
Gi 20 Set 2014 10:30
Modo
2 3
10 Date
Measured ambient temperature
11
12 Modulation percentage
Flame
13
14 Controlled area
Request for heating (rad) or hot water (tap)
15
Heat pump operating
16
Action carried out by pressing button (A)
17
Fig. 2
7
6
5
4
Fig. 1
