29.7.54 PIO Parallel Capture Reception Holding Register
Name: PIO_PCRHR
Address: 0x400E0F64 (PIOA), 0x400E1164 (PIOB), 0x400E1364 (PIOC)
Access: Read-only
31 30
23 22
15 14
7 6
• RDATA: Parallel Capture Mode Reception Data.
If DSIZE = 0 in PIO_PCMR, only the 8 LSBs of RDATA are useful.
If DSIZE = 1 in PIO_PCMR, only the 16 LSBs of RDATA are useful.
SAM4S Series [Preliminary]
588
29 28
RDATA
21 20
RDATA
13 12
RDATA
5 4
RDATA
27 26
19 18
11 10
3 2
25 24
17 16
9 8
1 0
