35.7.17 TC QDEC Interrupt Mask Register
Name: TC_QIMR
Address: 0x400100D0 (0), 0x400140D0 (1)
Access: Read-only
31 30
– –
23 22
– –
15 14
– –
7 6
– –
• IDX: InDeX
0 = The interrupt on IDX input is disabled.
1 = The interrupt on IDX input is enabled.
• DIRCHG: DIRection CHanGe
0 = The interrupt on rotation direction change is disabled.
1 = The interrupt on rotation direction change is enabled.
• QERR: Quadrature ERRor
0 = The interrupt on quadrature error is disabled.
1 = The interrupt on quadrature error is enabled.
11100B–ATARM–31-Jul-12
29 28
– –
21 20
– –
13 12
– –
5 4
– –
SAM4S Series [Preliminary]
27 26
– –
19 18
– –
11 10
– –
3 2
– QERR
25 24
– –
17 16
– –
9 8
– –
1 0
DIRCHG IDX
