• RINDE: Response Index Error
0 = No error.
1 = A mismatch is detected between the command index sent and the response index received. Cleared when writing in
the HSMCI_CMDR.
• RDIRE: Response Direction Error
0 = No error.
1 = The direction bit from card to host in the response has not been detected.
• RCRCE: Response CRC Error
0 = No error.
1 = A CRC7 error has been detected in the response. Cleared when writing in the HSMCI_CMDR.
• RENDE: Response End Bit Error
0 = No error.
1 = The end bit of the response has not been detected. Cleared when writing in the HSMCI_CMDR.
• RTOE: Response Time-out Error
0 = No error.
1 = The response time-out set by MAXLAT in the HSMCI_CMDR has been exceeded. Cleared when writing in the
HSMCI_CMDR.
• DCRCE: Data CRC Error
0 = No error.
1 = A CRC16 error has been detected in the last data block. Cleared by reading in the HSMCI_SR register.
• DTOE: Data Time-out Error
0 = No error.
1 = The data time-out set by DTOCYC and DTOMUL in HSMCI_DTOR has been exceeded. Cleared by reading in the
HSMCI_SR register.
• CSTOE: Completion Signal Time-out Error
0 = No error.
1 = The completion signal time-out set by CSTOCYC and CSTOMUL in HSMCI_CSTOR has been exceeded. Cleared by
reading in the HSMCI_SR register. Cleared by reading in the HSMCI_SR register.
• FIFOEMPTY: FIFO empty flag
0 = FIFO contains at least one byte.
1 = FIFO is empty.
• XFRDONE: Transfer Done flag
0 = A transfer is in progress.
1 = Command register is ready to operate and the data bus is in the idle state.
