Summary of Contents for Atmel SMARTCARD XPRO
-
Page 1: Preface
SMART ARM-based Microcontrollers SMARTCARD XPRO USER GUIDE Preface ® Atmel SMARTCARD Xplained Pro is an extension board to the Atmel Xplained Pro evaluation platform. Atmel SMARTCARD Xplained Pro is designed to connect with SAM L22 Xplained Pro. Atmel-42560A-SMARTCARD-XPRO_User Guide-01/2016... -
Page 2: Table Of Contents
Features............................3 1.2. Kit Overview..........................3 2. Getting Started......................4 2.1. Three Steps to Start Exploring the Atmel Xplained Pro Platform..........4 2.2. Connecting the SMARTCARD Xplained Pro to the Xplained Pro MCU Board......4 2.3. Design Documentation and Related Links................... 4 3. -
Page 3: Introduction
SAM L22 Xplained Pro kit using a ISO7816 module on the SAM L22 chip. It has ID chip to store the board details to identify the extension board when seen from Atmel Studio. -
Page 4: Getting Started
Xplained Pro EXT headers that can be used. Once the Xplained Pro MCU board is powered, the green power LED will be lit and Atmel Studio will auto- detect which Xplained Pro MCU and extension board(s) are connected. Atmel Studio will present relevant information like datasheets and kit documentation. -
Page 5: Xplained Pro
When an Xplained Pro extension board is connected to an Xplained Pro board the information is read and sent to Atmel Studio. The Atmel Kits extension, installed with Atmel Studio, will give relevant information, code examples, and links to relevant documents. Table 3.1 "Xplained Pro ID Chip... - Page 6 Always implemented, bus type. SPI_MISO Master in slave out line of Serial peripheral interface. Always implemented, bus type. SPI_SCK Clock for Serial peripheral interface. Always implemented, bus type. Ground Power for extension board Atmel SMARTCARD XPRO [USER GUIDE] Atmel-42560A-SMARTCARD-XPRO_User Guide-01/2016...
-
Page 7: Hardware User Guide
ID_DATA Communication to the ID chip Ground CARD_DETECT Card Detect GCLK GCLK Signal RESET Card Reset (GPIO generated) VCC_ENABLE Card VCC Enable USART Clock USART Input/Output (Bidirectional) Ground VCC_TARGET Target supply voltage (3.3V) Atmel SMARTCARD XPRO [USER GUIDE] Atmel-42560A-SMARTCARD-XPRO_User Guide-01/2016... -
Page 8: Hardware Revision History And Known Issues
5.1. Identifying Product ID and Revision The revision and product identifier of Xplained Pro boards can be found in two ways; through Atmel Studio or by looking at the sticker on the bottom side of the PCB. By connecting an Xplained Pro board to a computer with Atmel Studio running, an information window will pop up. -
Page 9: Document Revision History
Document Revision History Doc. rev Date Comment 42650A 01/2016 Initial document release Atmel SMARTCARD XPRO [USER GUIDE] Atmel-42560A-SMARTCARD-XPRO_User Guide-01/2016... -
Page 10: Evaluation Board/Kit Important Notice
(WEEE), FCC, CE or UL (except as may be otherwise noted on the board/kit). Atmel supplied this board/kit "AS IS," without any warranties, with all faults, at the buyer's and further users' sole risk. The user assumes all responsibility and liability for proper and safe handling of the goods. - Page 11 DISCLAIMER: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN THE ATMEL TERMS AND...
