Preface
®
The Atmel
SAM4L Xplained Pro evaluation kit is a hardware platform to
evaluate the ATSAM4LC4C microcontroller.
Supported by the Atmel Studio integrated development platform, the kit
provides easy access to the features of the Atmel ATSAM4LC4C and
explains how to integrate the device in a customer design.
The Xplained Pro MCU series evaluation kits include an on-board
Embedded Debugger, and no external tools are necessary to program or
debug the ATSAM4LC4C.
The Xplained Pro extension series evaluation kits offers additional
peripherals to extend the features of the board and ease the development of
customer designs.
SMART ARM-based MCUs
SAM4L Xplained Pro
USER GUIDE
Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015
Advertisement
Table of Contents
Related Manuals for Atmel SAM4L Xplained Pro
Summary of Contents for Atmel SAM4L Xplained Pro
-
Page 1: Preface
USER GUIDE Preface ® The Atmel SAM4L Xplained Pro evaluation kit is a hardware platform to evaluate the ATSAM4LC4C microcontroller. Supported by the Atmel Studio integrated development platform, the kit provides easy access to the features of the Atmel ATSAM4LC4C and explains how to integrate the device in a customer design. -
Page 2: Table Of Contents
VLCD_A and VLCD_BC Jumpers................21 4.4.4. VCC_MCU Jumper...................... 22 5. Appendix........................23 5.1. Getting Started with IAR......................23 6. Hardware Revision History and Known Issues............26 6.1. Identifying Product ID and Revision................... 26 6.2. Revision 2...........................26 Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015... - Page 3 7. Document Revision History..................27 8. Evaluation Board/kit Important Notice..............28 Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015...
-
Page 4: Introduction
32kHz crystal 1.2. Kit Overview The Atmel SAM4L Xplained Pro evaluation kit is a hardware platform to evaluate the Atmel ATSAM4LC4C. The kit offers a set of features that enables the SAM4L user to get started using the SAM4L's peripherals right away and to get an understanding of how to integrate the SAM4L in their own design. - Page 5 Figure 1-1 SAM4L Xplained Pro Evaluation Kit Overview Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015...
- Page 6 Figure 1-2 SAM4L Xplained Pro Block Diagram Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015...
-
Page 7: Getting Started
, Windows 7, and Windows 8. Once the Xplained Pro MCU board is powered the green power LED will be lit and Atmel Studio will auto detect which Xplained Pro MCU- and extension board(s) are connected. Atmel Studio will present relevant information like datasheets and kit documentation. - Page 8 • Design Documentation - Package containing CAD source, schematics, BOM, assembly drawings, 3D plots, layer plots etc. • SAM4L Xplained Pro on the Atmel website - Atmel website link. Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015...
-
Page 9: Xplained Pro
Atmel Data Visualizer is used to send and receive data through DGI. The EDBG controls two LEDs on SAM4L Xplained Pro; a power LED and a status LED. Table 3-1 EDBG LED Control on page 9 shows how the LEDs are controlled in different operation modes. -
Page 10: Hardware Identification System
When an Xplained Pro extension is connected to an Xplained Pro MCU board the information is read and sent to Atmel Studio. The Atmel Kits extension, installed with Atmel Studio, will give relevant information, code examples, and links to relevant documents. -
Page 11: Xplained Pro Headers And Connectors
Receiver line of target device UART UART_TX Transmitter line of target device UART SPI_SS_A Slave select for SPI. Should preferably be unique. SPI_MOSI Master out slave in line of serial peripheral interface. Always implemented, bus type. Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015... -
Page 12: Xplained Pro Segment Lcd Connector
Segment 17 Segment 18 SEG18 SEG19 Segment 19 Segment 20 SEG20 SEG21 Segment 21 Segment 22 SEG22 SEG23 Segment 23 Segment 24 SEG24 SEG25 Segment 25 Segment 26 SEG26 SEG27 Segment 27 Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015... -
Page 13: Xplained Pro Power Header
Xplained Pro Power Header The power header can be used to connect external power to the SAM4L Xplained Pro kit. The kit will automatically detect and switch to any external power if supplied. The power header can also be used as supply for external peripherals or extension boards. -
Page 14: Hardware User Guide
4.1.1. Xplained Pro Standard Extension Headers The SAM4L Xplained Pro headers EXT1, EXT2, EXT3, and EXT4 offers access to the I/O of the microcontroller in order to expand the board e.g. by connecting extensions to the board. These headers all comply with the Xplained Pro standard extension header. All headers have a pitch of 2.54mm. - Page 15 SAM4L pin Function Shared functionality Communication line to ID chip on extension board PB03 ADCIFE/AD[4] PB04 ADCIFE/AD[5] PC15 GPIO LCD connector (EXT5) PC16 GPIO LCD connector (EXT5) PA08 TC/0/A0 LCD connector (EXT5) Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015...
- Page 16 PA16 GPIO LCD connector (EXT5) PA15 GPIO LCD connector (EXT5) PB14 TWIMS/3/TWD EXT2, EXT3, and LCD connector (EXT5) PB15 TWIMS/3/TWCK EXT2, EXT3, and LCD connector (EXT5) PB00 USART/0/RXD EXT1 PB01 USART/0/TXD EXT1 Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015...
-
Page 17: Segment Lcd Extension Connector
11 4.1.2. Segment LCD Extension Connector Extension connector EXT5 is a special connector for segment LCD displays. SAM4L Xplained Pro implements one Xplained Pro Segment LCD connector for Xplained Pro extensions. Table 4-5 Segment LCD Display Connector EXT5 Pin on EXT5... - Page 18 EXT2, EXT3, and EXT4 PB15 SEG37 EXT2, EXT3, and EXT4 PA23 SEG38 EXT1 PA24 SEG39 EXT1 Not Connected Not Connected VCC_P3V3 PC05 Backlight EXT2 Related Links Xplained Pro Segment LCD Connector on page 12 Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015...
-
Page 19: Current Measurement Header
QTouch Button The SAM4L Xplained Pro kit has one QTouch button and the connection to the SAM4L is shown in the table below. The QTouch sensor, a copper fill, is located on the second layer (GND) of the board. The sensor is shielded by the third and the bottome layer (VCC and signal layer respectively) and therefore the sensor is not affected by any touches from the back side of the board. -
Page 20: Led
RESET PC24 4.2.4. There is one yellow LED available on the SAM4L Xplained Pro board that can be turned ON and OFF. The LED can be activated by driving the connected I/O line to GND. Table 4-10 LED Connections Pin on SAM4L... -
Page 21: Jumper Description
Jumper Description The SAM4L Xplained Pro contains five jumpers that can be used to adjust the functionality of the board. You can locate the jumpers in kit overview picture at the start of the user guide. Here is a description of the jumpers. -
Page 22: Vcc_Mcu Jumper
This jumper connects VCC to the target MCU. This jumper can be replaced with an ampere meter to measure the current used by the target device. Remeber to mount this jumper or an ampere meter to make the target MCU work properly. Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015... -
Page 23: Appendix
Select System (default) as the reset method. In the category Debugger > CMSIS DAP, select the JTAG/SWD tab. Select SWD as the interface and optionally select the SWD speed. Figure 5-1 Select Target Device Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015... - Page 24 Figure 5-2 Select Debugger Figure 5-3 Configure Flash Loader Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015...
- Page 25 Figure 5-4 Configure Reset Figure 5-5 Configure Interface Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015...
-
Page 26: Hardware Revision History And Known Issues
6.1. Identifying Product ID and Revision The revision and product identifier of Xplained Pro boards can be found in two ways; either through Atmel Studio or by looking at the sticker on the bottom side of the PCB. By connecting an Xplained Pro MCU board to a computer with Atmel Studio running, an information window will pop up. - Page 27 Document Revision History Doc. rev. Date Comment 42074C 11/2015 Added the Appendix 42074B 05/2013 Corrected SW0 pin to PC24 from PA24 42074A 02/2013 Initial document release Atmel SAM4L Xplained Pro [USER GUIDE] Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015...
- Page 28 (WEEE), FCC, CE or UL (except as may be otherwise noted on the board/kit). Atmel supplied this board/kit "AS IS," without any warranties, with all faults, at the buyer's and further users' sole risk. The user assumes all responsibility and liability for proper and safe handling of the goods.
- Page 29 DISCLAIMER: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN THE ATMEL TERMS AND...
- Page 30 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Atmel ATSAM4L-XPRO ATSAM4L-XSTK...
