USING YOUR LINEA PRO 5

Barcode Scanner — 1D Barcodes
The Linea Pro 5 1D model uses a scan engine that supports one-dimensional (1D) barcode symbols.
The effective reading distance of the barcode reader varies depending on the barcode size.
To scan a 1D barcode:
1. Press the Scan button to activate the Linea Pro 5.
2. Position the scan head as close to the barcode label as possible so that the scan line crosses both
ends of the barcode as shown in the figure below.
3. Slowly pull the unit back, increasing the distance between the barcode and scan head, until the
barcode has been read by the scanner.
Scan Button
Linea Pro 5 User Manual
UM-00025 Version: A
Figure 9: 1D Barcode Scanning
15-20 cm
Page 17 of 31
