PRODUCT FEATURES

The Linea Pro 5 allows mobile employees to convert their iPod or Phone into a powerful solution for
the retail, warehousing, supply chain, ticketing and hospitality industries. The Linea Pro 5 includes
an encrypted or unencrypted 3-track magnetic stripe reader, optional 1D or 2D barcode scanner,
optional Bluetooth®, and optional RFID.
Feature
1D/2D Barcode Scanner
Magnetic Stripe Reader
(MSR)
Contactless Card
Reader (RFID)
Bluetooth
Compatibility
Syncing
Indicators
Battery Status
Use of the Barcode Scanning, Magnetic Card and/or RFID reader features requires the
installation of special software. Please contact your reseller to inquire about available
software, or contact Infinite Peripherals directly for recommendations on compatible third
party software solutions.
Linea Pro 5 User Manual
UM-00025 Version: A
Supports one-dimensional (1D) and two-dimensional (2D) barcode
symbols, which can be read in any direction (omni-directional). The
effective reading distance of the barcode reader varies depending on the
barcode size. The barcode scanner is also capable of reading barcodes on
an LCD screen.
Built-in magnetic stripe reader. The card reader incorporates a (3) track,
bi-directional magnetic read head, requiring a single swipe to read field
data from all three tracks.
RFID tag/card reader with read and write capability at 13.56 MHz. The
RFID reader incorporates several RFID formats, depending on the model
of your Linea Pro 5.
Available Bluetooth 2.0 SPP compatibility, which allows connection to a
Bluetooth peripheral such as a printer.
Enables your iOS to be synced with iTunes.
Four (4) LEDs indicate battery status levels and an electromagnetic
buzzer.
The battery status may be checked by pressing the Battery Status button.
Description
Page 8 of 31
