Pistol Grip for
Linea Pro® 6
(Model# CS-LP6-PG-NB)
QUICK START GUIDE
ASSEMBLY
1. Insert the Linea Pro 6 device into the
silicone sleeve provided. Ensure the
sleeve is installed and aligned properly
with the volume buttons, barcode
scanner and mini USB port.
2. Connect the USB ribbon of the Pistol
Grip to the mini USB port on the Linea
Pro 6 device.
3. Insert the USB end of the Linea Pro 6
device into the Pistol Grip first, then
push the rest of the device firmly into
place.
4. Ensure the silicone sleeve is tucked
neatly into the Pistol Grip casing.
ABOUT YOUR
1
3
PISTOL GRIP FOR LINEA PRO 6
Trigger
Barcode Scanner
2
4
Hand Strap
Mini USB
Connector
USB Ribbon
USB Port
