Voice Memory

The Voice Memory capability of the FTDX101D may be used to store and replay often repeated messag-
es. The Voice Memory includes five memories, each capable of storing up to a maximum of 20 seconds
of voice audio.
The Voice Memory may be operated from the Display Panel, or from the optional FH-2 Remote Control
Keypad, which plugs into the rear panel REM jack.

• Recording Your Own Voice in Memory

1. Select the SSB or AM mode.
When using FH-2, go to step 4.
2. Press the [FUNC] key.
3. Touch [REC/PLAY].
4. Touch [MEM] on the display or press the
[MEM] key on the FH-2.
A blinking "REC" will appear in the display.
If a [1] through [5] key (see next step) is not
pressed within five seconds, the memory
storage process will be cancelled.
5. Touch [1] through [5] on the display or press
any of the FH-2 keys numbered [1] through [5]
to select that memory storage register.
6. Press the microphone PTT switch momen-
tarily. The "REC" icon will glow steadily and
recording will begin.
● Remember that the time limit for recording
any message is 20 seconds.
7. Touch [MEM] on the display or press the FH-2
[MEM] key to complete the message storage
process.
50

• Checking the Recording

1. Be sure that [BK-IN] function is "OFF" so
transmit will not be activated (the LED imbed-
ded in the [BK-IN] key must be Off).
When using FH-2, go to step 4.
2. Press the [FUNC] key.
3. Touch [REC/PLAY].
4. Touch [1] through [5] on the display or press
the FH-2 [1] through [5] key (whichever regis-
ter was just recorded in). The "MSG" icon will
appear in the display and the audio recorded
in the Voice Memory will be heard.
● To adjust the playback volume level, touch,
[RX LEVEL] and turn the [MULTI] knob.

• Transmitting the Recorded Message

1. Select the SSB, AM or FM mode.
Be sure the [BK-IN] functions is "ON" so
transmit will be activated (the LED imbedded
in the [BK-IN] key must be On).
When using FH-2, go to step 4.
2. Press the [FUNC] key.
3. Touch [REC/PLAY] .
4. Touch [1] through [5] on the display or press
the FH-2 [1] through [5] key (whichever
memory was recorded in). A "MSG" icon will
appear in the display and the message will be
transmitted.
● To adjust the output level during transmit,
touch [TX LEVEL] and turn the [MULTI]
knob.
