Operation Manual Erratum
There is an error in the FTDX101 series Operation Manuals
regarding item "
*Depending on the manual version.
Incorrect:
DVI-I connector for connecting an external monitor.
Correct:
DVI-D connector for connecting an external monitor.
Please use the DVI-D connector to connect between the
transceiver and the external monitor.
EXT-DISPLAY" on page 13* or 17*.
YAESU MUSEN CO., LTD.
EH068H506

Advertisement

Table of Contents
loading

Related Manuals for Yaesu FTDX101MP

Summary of Contents for Yaesu FTDX101MP

  • Page 1 *Depending on the manual version. Incorrect: DVI-I connector for connecting an external monitor. Correct: DVI-D connector for connecting an external monitor. Please use the DVI-D connector to connect between the transceiver and the external monitor. YAESU MUSEN CO., LTD. EH068H506...
  • Page 2 Updated Functions 1 The scope “LEVEL” adjustment function has been added to the C.S (custom select) key. 2 When CW keying speed is 45 wpm or more, QSK DELAY TIME (time between keying and actual transmission) is fixed to 15 msec. 3 When transmitting by the [MOX] key, modulation is input from the “MIC”...
  • Page 3 Description: MIC: Audio/Data is input from the MIC jack on the front panel. REAR: Disables the microphone circuit on the front panel and inputs audio/data from the USB jack or RTTY/DATA jack on the rear panel. YAESU MUSEN CO., LTD.
  • Page 4 101MP 101D Operation Manual...
  • Page 6 In order to gain the most enjoyment and operating efficiency from the FTDX101MP/FTDX101D, we recommend that you read this manual in its entirety, and keep it handy for reference as you explore the many capabilities of this new transceiver.

  • Page 7: Table Of Contents

    Antenna Connections ........9 Changing the number of QMB channels ..35 Power Cable Connections ....... 10 Mark the operation band ......35 FTDX101MP ..........10 Quick Split Operation ........37 FTDX101D ..........11 Direct input of offset frequency ....37 Clarifier ............
  • Page 8 Connecting to the Data Communications Receiver ............116 Device ............. 69 Index ............117 PSK Decode ............ 70 YAESU LIMITED WARRANTY ....120 PSK Text Memory ..........71 Text Message Programming on TFT Screen ..........71 Text Message Programming on FH-2 Remote Controller ......71 Text Input .............

  • Page 9: General Description

    Further, the excellent dynamic range and IP3 characteristics optimize the processing of all signals ranging from faint to powerful. * The 300 Hz roofing filter is also standard equipment on the MAIN band side of the FTDX101MP. Adopts 3DSS/Hybrid Dual SDR Display In addition to the conventional waterfall display, a 3DSS (3 Dimensions Spectrum Stream) image method has been newly adopted.
  • Page 10 Reliable High-output Final Amplifier Stage FTDX101MP (200W) power amplifier utilizes push-pull VRF150 MOS FET devices, operating at 50V, with excellent linearity, low distortion and high voltage tolerance. By optimizing the bias circuit for the optimal operating points, a high-quality and stable output with low distortion is realized.

  • Page 11: Safety Precautions

    Safety Precautions Note beforehand that the company shall not be liable for any damages suffered by the customer or third parties in using this product, or for any failures and faults that occur during the use or misuse of this prod- uct, unless otherwise provided for under the law.
  • Page 12 Refrain from using headphones and ear- Do not allow metallic objects such as wires and water to get inside the product. phones at a loud volume. This may result in fire, electric shock and equip- Continuous exposure to loud volumes may result ment failure.

  • Page 13: Accessories & Options

    • World Map • Circuit Diagrams • Sticker • The following items are included only with FTDX101MP: • External Power Supply with Speaker FPS-101 • AC Power Cord (for FPS-101) • DC Power Cord (for FPS-101) (USA version: T9101692, Asian and European version: T9207902) •...

  • Page 14: Installation And Interconnections

    Installation and Interconnections Antenna Considerations The FTDX101MP/FTDX101D is designed to connect to a 50 Ohm resistive impedance antenna at the Amateur operating frequencies. Select an appropriate antenna (dipole antenna, YAGI antenna, cubical quad antenna, etc.) that is suitable for the chosen operation and bands.

  • Page 15: Power Cable Connections

    Use the DC power cable supplied with the FTDX101MP to make the power connection to the FPS-101 power supply. • Connect the FTDX101MP and FPS-101 with the supplied speaker cable so audio can be output from the FPS-101’s built-in speaker.

  • Page 16: Ftdx101D

    Do not slack Do not excessively place the cord clamp Do not slack near the FTDX101MP or FPS-101. • FTDX101D Carefully follow the illustrations regarding the proper connection of the DC power cable. Use the DC power cable supplied with the FTDX101D to make the power connections to the power sup- ply.
  • Page 17 Installation guidelines • Do not expose the transceiver to direct sunshine. • Do not expose the transceiver to dust or high humidity. • Ensure adequate ventilation around the transceiver, to prevent heat build-up and possible reduction of performance due over heating. • Do not install the transceiver in a mechanically unstable location, or where objects may fall onto it from above. • When installing the FTDX101MP and FPS-101, be careful not to forcibly bend or pull the power cable. • Do not place heavy objects on top of the power cable. • Do not use a power cable other than the one that is provided. • To minimize the possibility of interference to home entertainment devices, take all precautionary steps including separation of TV/FM antennas from Amateur transmitting antennas to the greatest extent pos- sible. Keep the transmitting coaxial cables separated from cables connected to home entertainment de- vices. • Make sure to turn the transceiver OFF and disconnect all cables before moving the FTDX101MP or FPS-101. • The AC Power Cord connected to a socket-outlet with earthing connection. A socket-outlet with earthing connection shall connect to protective earthing conductor. Caution Be sure that both the transceiver Front Panel POWER switch and the FPS-101 Main Power switch are both turned OFF any time you plug or unplug the power cable to the FTDX101MP and FPS-101. This will avoid potentially damaging electrical spikes and electrical shock. When disconnecting the power cable, hold the connector, press the lock tab to release it and pull the plug from the connector. Pulling the power cable without releasing the lock may cause a failure.

  • Page 18: Microphone, Headphone, Key, Keyer And Fh-2 Connections

    Microphone, Headphone, Key, Keyer and FH-2 Connections φ6.3mm MIC GND FAST (as viewed from front panel) Remote Control Keypad FH-2 EXT SPKR METER EXT ALC RS-232C ANT 1 ANT 2 LINEAR +13.8V TUNER Key-up voltage on the front key jack is approximately +3.3 V DC, and key-down current is approximately 1 mA. Key-up voltage on the rear key jack is approximately +5.0 V DC, and key-down current is approximately 3 mA.

  • Page 19: Linear Amplifier Interconnections

    • VL-1000 Linear Amplifier Interconnections Since the FTDX101MP has a high transmission output of 200 W, be sure to turn ON the ATT switch of the VL- 1000. Using the amplifier with the ATT switch “OFF” may damage the VL-1000.

  • Page 20: Interfacing To Other Linear Amplifiers

    +13.8V TUNER DC IN LINEAR EXT ALC D-sub 15 pin TX GND The figure above shows the FTDX101MP rear panel connections to other linear amplifiers. Coaxial Cable (50 ohm) HF/50 MHz Antenna ANT 1 RF IN RF OUT EXT SPKR...

  • Page 21: Rear Panel

    EXT ALC RS-232C ANT 1 ANT 2 LINEAR +13.8V TUNER The figure above shows the rear panel of the FTDX101MP. Cooling FAN ANT 1, 2, 3/RX DASH COMMON Connect the main antenna(s) here, using type-M When connecting an electronic keyer paddle (PL-259) connectors and coaxial feed lines.
  • Page 22 A USB driver is re- signal. This signal does not pass through the roof- quired for remote control from a computer. Down- ing filter. load the driver from the Yaesu website (http://www. yaesu.com). TX-GND RS-232C This RCA jack’s center pin is closed to ground while SERIAL IN the transceiver’s transmitter is engaged.

  • Page 23: Ssm-75G Microphone Switches

    SSM-75G Microphone Switches MUTE PTT Switch MUTE Key Switches Transmit/Receive. While pressing the MUTE key, the receiver audio Press to transmit and release to receive. from the speaker will be muted. DWN / UP Key Microphone The [UP]/[DWN] keys may also be used to manual- Speak into the microphone in a normal tone of ly scan the frequency upward or downward.

  • Page 24: Be Sure To Study This Information To Maximize The Receiver Performance Of The High-Class Ftdx101 Series Shortwave Transceiver

    Touch [R.FIL] on the TFT screen to select the 3kHz filter for SSB, the 1.2kHz filter or the 600Hz filter for CW. An optional 300Hz* filter is also available. * Included with FTDX101MP. Use DSP interference removal functions DSP interference removal functions include IF SHIFT, IF WIDTH, IF NOTCH, APF, CONTOUR, and DNR.

  • Page 25: Display Indications

    Display Indications Meter & Filter images Frequency area Function settings Spectrum Scope Display setting keys Display setting keys Meter Display Meter Operations during Transmission S-Meter S-Meter (MAIN band) (SUB band) Final transistor RF power Output Relative ALC voltage Final amplifier drain voltage temperature Speech compressor level Final amplifier drain current...

  • Page 26: Filter Function Display

    Filter Function Display Displays the passband status of the DSP filter. The operation of WIDTH, SHIFT, NOTCH, CONTOUR etc. can be observed. SSB Mode CW Mode RTTY Mode PSK/DATA Mode The current roofing filter bandwidth is displayed as a blue line below the filter function display.

  • Page 27: Important Receiver Settings

    Important Receiver Settings The status of various operations that are important during receive, are shown at the bottom of the display. To change a setting, touch the appropriate location on the display. Important setting items when receiving ANT (Switching the Antenna) The currently used antenna terminal number The IPO (Intercept Point Optimization) function can establish the gain of the RF amplifier section...

  • Page 28: R.fil (Roofing Filter Switching)

    * 300Hz & 1.2kHz roofing filters are optional. mum receiver-recovery time for the reception (300Hz is included on the MAIN side with the mode. FTDX101MP) Operating Mode AUTO AGC Selection After touching [R. FIL], touch the desired filter. SSB / AM SLOW If the optional 300Hz and 1.2kHz filters are not...

  • Page 29: Scope Display Setting

    Scope Display Setting In addition to the conventional two-dimensional waterfall spectrum display, Yaesu has added the 3-Dimen- sion Spectrum Stream (3DSS) color display. The constantly changing band conditions and signals are depicted in real time and color. The frequency span is shown on the horizontal X axis, the vertical Y axis depicts the signals and their strengths, and the time is represented on the receding Z axis.

  • Page 30: Fix

    • FIX 3DSS To use Fixed Mode, enter the start frequency of the Switch between the 3DSS display and the waterfall scope. display. The display will change each time it is touched: To adjust the level of the SUB band, press the [SUB] key to make the operation band a SUB band.
  • Page 31 MULTI HOLD In addition to the scope display, the oscilloscope Temporarily stops the operation of the Scope Dis- and AF-FFT are also presented. play and the Filter Function Display. Touch the dis- Touch again to return to the original screen. play to enter HOLD state, touch it again to restore Scope operation.

  • Page 32: Speed

    S.MENU On the SCOPE MENU screen, enter settings related to the Scope Display. Press the [S.MENU] key to display the SCOPE MENU screen. Touch the desired item to set. SCOPE MENU display MULTI knob Operation display MULTI knob S.MENU key SPEED Sets the Scope Display sweep speed.
  • Page 33 Function Menu Display MULTI knob FUNC key Press the [FUNC] key to call up the function screen for setting various functions. The setting menu (page 88) is also called from the function screen. Press again to return to the normal operation screen. Touch a MENU item, or rotate the [MULTI] control knob to make a selection.

  • Page 34: Other On-Screen Indications

    Other On-Screen Indications BUSY: Lights up while receiving a signal. M-xx: Displays the selected channel number in Lights up during transmission. memory mode. Lights in plus shift (repeater operation). Lights up during memory tuning opera- Lights in negative shift (repeater opera- tion.

  • Page 35: Screen Saver

    Font setting for Screen Saver frequency display A Screensaver, to prevent burning of the TFT The height of the frequency display can be varied. screen will operate after a set time, if no trans- ceiver function is operated. 1. Press the [FUNC] key. 2.
  • Page 36 Note...

  • Page 37: Front Panel Controls & Switches

    (grounded) shaft of the plug, resulting in a This 8-pin jack accepts input from a microphone uti- constant “key-down” condition. lizing the traditional YAESU HF transceiver pinout. MIC GND DASH COMMON FAST Key-up voltage is approximately +3.3 V...

  • Page 38: Adjusts The Vox Gain

    TUNE This is the ON/OFF switch for the FTDX101 Auto- Pressing this key engages the PTT (Push to Talk) matic Antenna Tuner. circuit to activate the transmitter. Press the [TUNE] key briefly to activate the antenna tuner. Press the [TUNE] key briefly again to disable ZIN/SPOT the antenna tuner.
  • Page 39 FAST MAIN dial The MAIN dial sets the operating frequency. Pressing this key will change the tuning of the Rotate the MAIN dial knob to tune within the band, MAIN Dial knob and [MULTI] knob (When STEP and begin normal operation. DIAL function is assigned) to a higher step rate.

  • Page 40: Qmb Channel Storage

    QMB (Quick Memory Bank) • Confirm the contents of QMB You can display the contents memorized in QMB The current operation status can be stored in a on the screen to check the data. dedicated memory channel (QMB: Quick Memory Bank) with one touch.
  • Page 41 MODE/SSB/CW MONI Switch the operating mode. Use the Monitor feature to listen to the quality of Press and hold the [MODE] key, then touch the de- your transmitted signal. While activated, the LED sired operating mode. inside this key glows orange. Press it briefly to set the previously selected oper- 1.

  • Page 42: Quick Split Operation

    • Quick Split Operation SPLIT A powerful capability of the FTDX101 is its flexibility The Quick Split feature allows setting a one-touch offset of +5 kHz as compared to the MAIN band fre- in Split Frequency operation using the MAIN band quency, to be applied to the transceiver SUB band and SUB band frequency registers.
  • Page 43 MPVD ring (MULTI PURPOSE VFO OUTER DIAL) Select the MPVD operation by touching one of the keys: MAIN/SUB dial, VC TUNE, CLAR (Clarifier), C.S (Custom Select). Change the function of the MPVD ring The function of the MPVD ring can be changed simply by pressing the key below. CLAR (Clarifier) VC TUNE VC TUNE Operation key C.S (Costom Select key) MAIN/SUB MPVD ring CLAR: Acts as a clarifier knob. VC TUNE: Adjusts the tuning point when the VC tune function is activated. C.S: 12 types of functions can be assigned in advance. MAIN / SUB: Operates as a dial to set the frequency of the SUB band when the operation band is the MAIN band, and as the frequency of the MAIN band when the operation band is the SUB band.

  • Page 44: Clarifier

    Clarifier • TX Clarifier The transmit frequency can be changed without The clarifier is used to adjust the receiver frequency moving the receive frequency of the transceiver. Normally, the clarifier is used to move only the re- of this transceiver to match the other station trans- ceive frequency and compensate for the deviation mit frequency and improve the audio;...

  • Page 45: Vc Tune

    SUB band. the ring tunes the frequency of the use it on the SUB band of the FTDX101D, MAIN band. please contact Yaesu. The VC tune function works only with amateur bands from 1.8 MHz band to 29 MHz (except the 5 MHz band).
  • Page 46 RX (MAIN band) RX (SUB band) Press this key to activate receive on the SUB band Press this key to activate receive on the MAIN band frequency. The LED inside the key will glow green frequency. The LED inside the key will glow green when the transceiver is receiving on the SUB band when the transceiver is receiving on the MAIN band frequency.

  • Page 47: Switching The Operation Of The [Rf/Sql] Knob

    MAIN AF, RF/SQL • Switching the operation of the [RF/SQL] knob Inner Knob (MAIN AF) The inner [MAIN AF] knob sets the audio level of 1. Press the [FUNC] key. the MAIN band receiver. 2. Select [OPERATION SETTING]→[GENERAL] Outer Knob (RF/SQL) →...
  • Page 48 SUB AF, RF/SQL MIC/SPEED, PROC/PITCH Inner Knob (SUB AF) Inner Knob (MIC/SPEED) The inner [SUB AF] knob sets the audio level of the Adjusts the microphone gain (microphone sensitivi- SUB band receiver. ty) (0 to 100) in SSB and AM modes. It is similar to the MAIN Band knob operation.

  • Page 49: Main Band Operation

    MAIN Band Operation • Reduces longer duration pulse noise Reduces long duration noise as well as pulse noise. The FTDX101 includes an effective IF Noise Blank- er, which can significantly reduce noise caused by 1. Press the [FUNC] key. 2. Select [OPERATION SETTING]→[GENERAL] automotive ignition systems.
  • Page 50 DNR (Digital Noise Reduction) NOTCH (IF NOTCH Filter) The Digital Noise Reduction (DNR) system is de- The IF NOTCH filter is a highly effective system signed to reduce the level of ambient noise found that allows you to slice out an interfering beat note on the HF and 50 MHz bands.

  • Page 51: Adjust The Gain Of The Contour Circuit

    For the SUB band, the same functions as operate. CONT (Contour) • Sets the Bandwidth (“Q”) of the CONTOUR Circuit The Contour filter system provides a gentle per- turbation of the IF filter passband. The Contour is 1. Press the [FUNC] key. set to either suppress, or boost specific frequency 2.
  • Page 52 APF (Audio Peak Filter) SHIFT, WIDTH Inner Knob (SHIFT) During CW operation, when interference or noise is present, the center frequency is automatically set to IF SHIFT permits moving the DSP filter passband the PITCH frequency, making it easier to hear the higher or lower, without changing the pitch of the desired signal.
  • Page 53 Outer Knob (WIDTH) Referring to Figure “B", you can see the default The IF WIDTH tuning system allows you to vary the bandwidth of the SSB mode. width of the DSP IF passband, to reduce or elimi- nate interference. By rotating the [SHIFT] knob to the left, the Moreover, the bandwidth may actually be expanded bandwidth will narrow (see Figure “A”), while from its default setting, should you wish to enhance...
  • Page 54 NOTCH, CONT/APF Inner Knob (NOTCH) Rotate the inner [NOTCH] knob to adjust the cen- ter frequency of the IF NOTCH filter. Press the [NOTCH] key to turn the IF NOTCH filter ON or OFF. The null position of the IF NOTCH filter can be ob- served on the display.

  • Page 55: Voice Communications (Ssb And Am)

    Voice Communications (SSB and AM) When transmitting in SSB or AM mode The FTDX101 series transmit audio circuit can be set to the optimum operating level by individually ad- justing the input and output gains of the microphone amplifier. The AMC (Automatic Microphone Gain Control) regulates the microphone audio so that distortion does not oc- cur, even if excessive audio is input.

  • Page 56: Speech Processor

    Microphone Equalizer (page 52). imum (carrier) power output of 50 Watts (for 7. Touch the left meter area on the display to se- FTDX101MP) or 25 Watts (for FTDX101D). lect the “COMP” meter. ● Setting of maximum transmission output The transmit meter becomes the “COMP”...

  • Page 57: Parametric Microphone Equalizer

    Parametric Microphone Equalizer The FTDX101 includes a unique Three-Band Parametric Microphone Equalizer that provides precise, in- dependent control over the low, mid and treble ranges in the voice waveform. One group of settings may be utilized when the AMC or speech processor is Off, and an alternate group of settings when the AMC or Speech Processor is On (SSB mode only).
  • Page 58 Parametric Gain 3-Stage Parametric Equalizer Adjustments (Speech Processor: “OFF”) PRMTRC EQ1 FREQ (Low) “100” (Hz) - “700” (Hz) / OFF Center Frequency PRMTRC EQ2 FREQ (Mid) “700” (Hz) - “1500” (Hz) / OFF PRMTRC EQ3 FREQ (High) “1500” (Hz) - “3200” (Hz) / OFF PRMTRC EQ1 LEVEL (Low) “-10”...

  • Page 59: Voice Memory

    Voice Memory The Voice Memory capability of the FTDX101 may be used to store and replay often repeated messages. The Voice Memory includes five memories, each capable of storing up to a maximum of 20 seconds of voice audio. The Voice Memory may be operated from the Display Panel, or from the optional FH-2 Remote Control Keypad, which plugs into the rear panel REM jack.

  • Page 60: Adjustable Receiver Audio Filter

    Adjustable Receiver Audio Filter The FTDX101 incorporates an adjustable receiver audio filter, that affords precision control of the low; lower and upper audio ranges independently. 1. Press the [FUNC] key. 2. Select [RADIO SETTING] . 3. Select the Mode and Menu Item you want to set (see table below).

  • Page 61: Using The Automatic Antenna Tuner

    Using the Automatic Antenna Tuner The Automatic Antenna Tuner (ATU) is built into each FTDX101 series. The ATU is designed to ensure that a 50-Ohm antenna impedance load is presented to the final amplifier stage of the transmitter. • Because the FTDX101 ATU is located inside transceiver, it can only adjust the impedance presented to the transceiver end of the coaxial cable feedline. It does not “tune” the SWR at the antenna feed point itself.
  • Page 62 Figure 1 depicts a situation where normal tuning via the ATU has been successfully completed, and the tuning data has been stored in the ATU memory. The antenna system SWR as seen by the transmitter is shown. In Figure 2, the operator has changed frequency, and the “HI-SWR” icon has appeared. The operator presses and holds in the TUNE button for one second to begin impedance matching using the ATU.

  • Page 63: Cw Mode Operation

    CW Mode Operation ● T h e s a m e o p e r a t i n g f r e q u e n c y m a y The impressive CW operating capabilities of the b e m a i n t a i n e d a n d d i s p l a y e d w h e n FTDX101 permit operating with an Electronic switching the transceiver between SSB Keyer Paddle, a “Straight Key”, or a computer...

  • Page 64: Cw Decode

    CW Spotting (Zero-Beating) CW Decode Alphanumeric Morse code can be decoded and “Spotting” (zeroing in on another CW station) is displayed as text on the TFT Panel. a handy technique to ensure the transceiver and the other station are operating precisely on the Interfering signals, noise, propagation phasing, same frequency.

  • Page 65: Setting Of The Electronic Keyer

    Setting of the Electronic Keyer • Adjusting the Keyer Speed • Selecting the Keyer Operating Mode Keyer speed can be adjusted by rotating the [MIC/ The configuration of the Electronic Keyer may SPEED] knob. be customized independently for the front and rear KEY jacks of the FT DX101.

  • Page 66: Contest Memory Keyer

    Contest Memory Keyer The CW message capability of the FTDX101 may be controlled either from the Transceiver Front Panel, or with the optional FH-2 Remote Control Keypad, which plugs into the rear panel REM jack. • Message Memory Five CW memory channels capable of retaining 50 characters each are available (using the PARIS stan- dard for characters and word length).

  • Page 67: Checking The Cw Memory Contents

    • Checking the CW Memory Contents • On-The-Air CW Message Playback 1. Be sure that Break-in is still turned “OFF” by 1. Press the [BK-IN] key to enable transmission. the [BK-IN] key. When using FH-2, go to step 4. 2. Press the [MONI] key to enable the CW mon- 2.

  • Page 68: Text Memory

    • TEXT Memory The five channels of CW message memory (up to 50 characters each) may also be programmed using a text-entry technique. This technique is somewhat slower than sending message directly from the keyer paddle, but accuracy of character spacing is ensured. Be sure to enter the character “}” at the end of the text message. Example 1: CQ CQ CQ DE W6DXC K} (20 characters) The sequential Contest Number (“Count up”) feature is another impressive feature of the CW Memory Keyer.

  • Page 69: Checking The Cw Memory Contents

    • Checking the CW Memory Contents • On-The-Air CW Message Playback 1. Set the operating mode to CW. 1. Press the [BK-IN] key to enable transmission. 2. Be sure that Break-in is still turned “OFF” by When using FH-2, go to step 4. the [BK-IN] key.

  • Page 70: Fm Mode Operation

    FM Mode Operation Repeater Operation Tone Squelch Operation The FTDX101 may be operated on 29 MHz and The “Tone Squelch” may be activated to keep the 50 MHz repeaters. receiver silent until an incoming signal modulated with a matching CTCSS tone is received. The 1.

  • Page 71: Rtty (Fsk) Operation

    To connect to a PC using a USB cable, a Virtual COM port driver must be installed on the PC. Visit the Yaesu website http://www.yaesu.com/ to download the Virtual COM port driver and Installation Manu- EXT SPKR...

  • Page 72: Rtty Decode

    Note that text will no longer be displayed for weak signals if the level is increased too much. CQ CQ CQ DE W6DXC W6DXC W6DXC K YAESU FTDX101D 3. The setting is concluded when 4 seconds have elapsed after making the level adjustment.

  • Page 73: Rtty Text Memory

    RTTY Text Memory Five phrases (up to 50 characters each) frequently used in RTTY exchanges can be entered into the Text Memory, either by operation on the TFT screen, or by using the optional “FH-2” Remote Control Keypad connected to the rear panel REM jack. 5 channels can be memorized, and the memory content can be transmitted by operation on screen or the FH-2.

  • Page 74: Data (Psk) Operation

    To connect to a PC using a USB cable, a Virtual COM port driver must be installed on the PC. Visit the Yaesu website http://www.yaesu.com/ to download the Virtual COM port driver and Installation Manu- EXT SPKR...

  • Page 75: Psk Decode

    3. The setting is concluded when 4 seconds have elapsed after making the level adjustment. CQ CQ CQ DE W6DXC W6DXC W6DXC K YAESU FTDX101D Displays content written to the PSK text memory. • Set the data output level for data communi- cations using Menu item “DATA OUT LEVEL”...

  • Page 76: Psk Text Memory

    PSK Text Memory Five phrases (up to 50 characters each) frequently used in PSK exchanges can be entered into the Text Memory, either by operation on the TFT screen, or by using the optional “FH-2” Remote Control Keypad connected to the rear panel REM jack. 5 channels can be recorded.

  • Page 77: Memory Operation

    Memory Operation • Erasing Memory Channel Data • Memory Storage The contents written to the memory channel may be erased. 1. Set the frequency, mode, and status, as de- sired. 1. Press the [V M] key. 2. Press the [V M] key.

  • Page 78: Check Memory Channel Status

    • Check Memory Channel Status Before programming a memory channel, the This key toggles frequency control between VFO current contents of that channel may be verified and the memory system. without the danger of over-writing the channel. The contents of the memory channels can be 1.

  • Page 79: Moving Memory Data To The Vfo Register

    • Displaying the Memory Tag • Moving Memory Data to the The “Frequency display” or “Alpha tag display” format may be selected. VFO register 1. Press the [V M] key. The contents of the currently selected Memory The memory channel list will be displayed. Channel may be transferred into the VFO register: 2.

  • Page 80: Memory Groups

    Memory Groups Choosing the Desired Memory Group Memory channels may be listed into as many as six convenient groups, for easy identification If desired, just the memories listed within a partic- and selection. For example: groups for AM BC ular Memory Group, may be recalled. stations, Short-wave broadcast stations, Contest Before performing the operation, set the “MEM frequencies, Repeater frequencies, PMS limits, or...

  • Page 81: Vfo And Memory Scanning

    VFO and Memory Scanning Either the VFO or the memory channels of the FTDX101 may be scanned, and the receiver will halt scan- ning on any frequency with a signal strong enough to open the receiver squelch. In the SSB/CW and SSB-based Data modes, the decimal points in the frequency display area will blink and the scanner will slow down (but does not stop).

  • Page 82: Programmable Memory Scan (Pms)

    Programmable Memory Scan (PMS) To limit scanning (and manual tuning) to a particular frequency range, the Programmable Memory Scan- ning (PMS) feature utilizes nine special-purpose memory pairs (“M-P1L/M-P1U through M-P9L/ M-P9U). The PMS feature is especially useful in helping to observe any operating sub-band limits which apply to your Amateur license class.

  • Page 83: Other Functions

    Other Functions TOT (Time Out Timer) Band Stack Operation The FTDX101 employs a triple band-stack VFO The “Time-Out Timer” (TOT) shuts the transmitter selection technique that permits storing up to OFF after continuously transmitting for the pro- three favorite frequencies and modes onto each grammed time.

  • Page 84: Operation On Alaska Emergency Frequency: 5167.5 Khz (U.s. Version Only)

    Operation on Alaska Screen capture Emergency Frequency: The display on the TFT screen may be saved on 5167.5 kHz the SD card. (U.S. Version Only) When performing screen capture, a commer- Section 97.401(d) of the regulations governing cially available SD card is necessary. amateur radio in the United States permit emer- For SD card information, refer to “Using the SD gency Amateur communications on the spot...

  • Page 85: Using The Sd Card

    4. Touch “START”, the SD card will be initialized. • Note that Yaesu shall not be liable for any Touch “BACK” to cancel the initialization. damages suffered as a result of data loss or 5.

  • Page 86: Menu Data

    • Saving Memory data and Setting Menu data The Memory Channel data, and the Setting Menu data can be saved to the SD Card: 1. Press the [FUNC] key. 7. Touch the screen to end saving data. 2. S e l e c t [ E X T E N S I O N S E T T I N G ] → [ S D 8.

  • Page 87: Reading Memory And Set Menu Data

    • Reading Memory and Set Menu data • Display the SD Card Information The Memory and Setting Menu data saved on the The memory free space of the SD card may be SD card may be read to the Transceiver. checked: 1.

  • Page 88: Setting Menu

    Setting Menu The Menu system of the FTDX101 series provides extensive customization capability. The transceiver functions can be tailored for the most demanding operators. The Setting Menus are grouped into five spe- cific utilization categories. Comprehensive settings such as: Transmit & Receive, Interference Reduction, Memory, Scan, etc.
  • Page 89 Menu Function Available Settings (Default: Bold) RADIO SETTING 20 - 300 - 4000 (20msec/step) MODE SSB AGC FAST DELAY 20 - 1000 - 4000 (20msec/step) AGC MID DELAY 20 - 3000 - 4000 (20msec/step) AGC SLOW DELAY LCUT FREQ OFF/100 - 1000 (50Hz/step) LCUT SLOPE 6dB/oct / 18dB/oct 700 - 3000 - 4000 (50Hz/step) / OFF...
  • Page 90 Menu Function Available Settings (Default: Bold) DATA OUT SELECT MAIN / SUB 0 - 50 - 100 DATA OUT LEVEL 50-3050 / 100-2900 / 200-2800 / 300-2700 / 400-2600 TX BPF SEL MIC / REAR DATA MOD SOURCE REAR SELECT DATA / USB 0 - 50 - 100 RPORT GAIN...
  • Page 91 Menu Function Available Settings (Default: Bold) NUMBER STYLE 1290 / AUNO / AUNT / A2NO / A2NT / 12NO / 12NT CONTEST NUMBER 1 - 999 CW MEMORY 1 TEXT / MESSAGE CW MEMORY 2 TEXT / MESSAGE CW MEMORY 3 TEXT / MESSAGE CW MEMORY 4 TEXT / MESSAGE...
  • Page 92 Menu Function Available Settings (Default: Bold) -10 - 0 - 10 P PRMTRC EQ1 LEVEL 0 - 2 - 10 P PRMTRC EQ1 BWTH OFF / 700 - 1500 (100Hz/step) P PRMTRC EQ2 FREQ -10 - 0 - 10 P PRMTRC EQ2 LEVEL 0 - 1 - 10 P PRMTRC EQ2 BWTH OFF / 1500 - 3200 (100Hz/step)
  • Page 93 HCUT SLOPE RADIO SETTING Function: Sets the slope of the high-frequency - MODE SSB - cutoff audio filter in SSB mode. Available Values: 6dB/oct / 18dB/oct AGC FAST DELAY Default Setting: 6dB/oct Function: Sets the AGC-FAST DELAY voltage SSB OUT SELECT decay characteristics for SSB mode. Available Values: 20 - 4000msec Function: SSB signal output band setting from Default Setting: 300msec...
  • Page 94 RPTT SELECT RADIO SETTING Function: Sets the PTT control for the SSB trans- - MODE AM - mit signal. Available Values: DAKY / RTS / DTR AGC FAST DELAY Default Setting: DAKY Description: Function: Sets the AGC-FAST DELAY voltage DAKY: Controls the SSB transmit signal from the decay characteristics for AM mode.
  • Page 95 HCUT SLOPE REAR SELECT Function: Selects the input jack of the AM signal. Function: Sets the slope of the high-frequency cutoff audio filter in AM mode. Available Values: DATA / USB Available Values: 6dB/oct / 18dB/oct Default Setting: DATA Default Setting: 6dB/oct Description: Selects the input jack of the AM sig- nal when “AM MOD SOURCE” is set AM OUT SELECT to “REAR”. DATA: Inputs from the RTTY/DATA jack on the Function: AM signal output band setting from rear panel. RTTY/DATA jack.
  • Page 96 HCUT SLOPE RADIO SETTING Function: Sets the slope of the high-frequency - MODE FM - cutoff audio filter in FM mode. Available Values: 6dB/oct / 18dB/oct AGC FAST DELAY Default Setting: 18dB/oct Function: Sets the AGC-FAST DELAY voltage FM OUT SELECT decay characteristics for FM mode. Available Values: 20 - 4000msec Function: FM signal output band setting from Default Setting: 160msec RTTY/DATA jack. Description: Sets the AGC voltage decay char- Available Values: MAIN / SUB acteristics in 20 msec steps after...
  • Page 97 RPTT SELECT RADIO SETTING Function: Sets the PTT control for the FM trans- - MODE PSK/DATA - mit signal. Available Values: DAKY / RTS / DTR AGC FAST DELAY Default Setting: DAKY Description: Function: Sets the AGC-FAST DELAY voltage DAKY: Controls the FM transmit signal from the decay characteristics for PSK/DATA RTTY/DATA jack (pin 3) on the rear panel.
  • Page 98 LCUT SLOPE REAR SELECT Function: Selects the input jack of the DATA sig- Function: Sets the slope of the low-frequency cutoff audio filter in DATA mode. nal. Available Values: 6dB/oct / 18dB/oct Available Values: DATA / USB Default Setting: 18dB/oct Default Setting: DATA Description: Selects the input jack of the AM sig- nal when “DATA MOD SOURCE” is HCUT FREQ set to “REAR”. Function: Sets the high-frequency cutoff audio DATA: Is input to the RTTY/DATA jack on the filter in DATA mode.
  • Page 99 LCUT FREQ RADIO SETTING Function: Sets the low-frequency cutoff audio fil- - MODE RTTY - ter in RTTY mode. Available Values: OFF / 100Hz - 1000Hz AGC FAST DELAY Default Setting: 300Hz Description: The cutoff frequency can be set at Function: Sets the AGC-FAST DELAY voltage 50 Hz increments between 100 Hz decay characteristics for RTTY mode.
  • Page 100 MARK FREQUENCY RADIO SETTING Function: Sets the mark frequency for RTTY - ENCDEC PSK - mode. Available Values: 1275 / 2125 (Hz) PSK MODE Default Setting: 2125Hz Function: Selects the operation mode of the PSK SHIFT FREQUENCY mode. Available Values: BPSK / QPSK Function: Sets the shift width for RTTY mode.
  • Page 101 RADIO SETTING BAUDOT CODE Function: Selects the Baudot Code used for the - ENCDEC RTTY - RTTY mode. Available Values: CCITT / US RX USOS Default Setting: US Function: Enables/Disables the RX USOS fea- ture. Available Values: OFF / ON Default Setting: ON Description: When the space symbol is received, the RX USOS function that automati-...
  • Page 102 HCUT SLOPE CW SETTING Function: Sets the slope of the high-frequency - MODE CW - cutoff audio filter in CW mode. Available Values: 6dB/oct / 18dB/oct AGC FAST DELAY Default Setting: 18dB/oct Function: Sets the AGC-FAST DELAY voltage CW OUT SELECT decay characteristics for CW mode.
  • Page 103 CW WAVE SHAPE CW SETTING Function: Selects the CW carrier wave-form - KEYER - shape (rise/fall times). Available Values: 1ms / 2ms / 4ms / 6ms F KEYER TYPE Default Setting: 4ms (msec) Description: Sets the rise and fall times of the Function: Selects the desired keyer operation keying envelope in CW mode (trans- mode for the device connected to the...
  • Page 104 R KEYER TYPE NUMBER STYLE Function: Selects the desired keyer operation Function: Selects the contest number “Cut” for- mode for the device connected to the mat for an imbedded contest number. rear panel KEY jack. Available Values: 1290 / AUNO / AUNT / A2NO / Available Values: OFF / BUG / ELEKEY-A / A2NT / 12NO / 12NT ELEKEY-B / ELEKEY-Y / ACS...
  • Page 105 CW MEMORY 3 CW SETTING Function: Selects the registration method for the - DECODE CW - contest keyer “CW MEMORY 3”. Available Values: TEXT / MESSAGE CW DECODE BW Default Setting: TEXT Description: Function: Selects the bandwidth of the AFC fea- TEXT: Use the optional FH-2 or the touch ture.
  • Page 106 OPERATION SETTING ANT3 SELECT Function: Operation selections for “ANT 3/RX” - GENERAL - connector. Available Values: TRX / R3-T1 / R3-T2 / RX-ANT DECODE RX SELECT Default Setting: TRX Description: Set the operation of the rear panel Function: Sets the band to decode in CW, RTTY antenna connector “ANT 3/RX”.
  • Page 107 RF/SQL VR CAT TIME OUT TIMER Function: Selects the operation mode of the RF/ Function: Sets the Time-Out Timer for a CAT SQL knob. command input. Available Values: RF / SQL Available Values: 10 / 100 / 1000 / 3000 (msec) Default Setting: RF Default Setting: 10 msec Description:...
  • Page 108 TX TIME OUT TIMER CS DIAL Function: Sets the Time-Out Timer countdown time. Function: Sets the Operation of MPVD dial when Available Values: OFF / 1 - 30 min the [C.S] key is pressed. Default Setting: OFF Available Values: RF POWER / MONI LVL / Description: When the time-out timer function DNR LVL / NB LVL / VOX GAIN is active, a beep is emitted when a...
  • Page 109 OPERATION SETTING OPERATION SETTING - RX DSP - - TX AUDIO - APF WIDTH PROC LEVEL Function: Sets the bandwidth of the Audio Peak Function: Sets the level of the AMC function and Filter. the speech processor function com- Available Values: NARROW / MEDIUM/WIDE pression level adjustment.
  • Page 110 PRMTRC EQ1 BWTH PRMTRC EQ3 LEVEL Function: Sets the width variation (“Q”) for the Function: Sets the gain for the high range of the low range of the 3 Band Parametric Mi- 3 Band Parametric Microphone Equal- crophone Equalizer. izer. Available Values: 0 - 10 Available Values: -10 - 0 - 10 (dB) Default Setting: 10...
  • Page 111 P PRMTRC EQ2 FREQ P PRMTRC EQ3 LEVEL Function: Selects the center frequency for the Function: Sets the gain for the high range of the middle range of the 3 Band Parametric 3 Band Parametric Microphone Equal- Microphone Equalizer when the AMC izer when the AMC or speech proces- or speech processor is activated.
  • Page 112 Sets the transmit RF power output of the spot frequency of 5167.5 kHz will the HF band. be enabled. The Alaska Emergency Available Values: 5 - 200W (FTDX101MP) Channel will be found between the 5 - 100W (FTDX101D) PMS memory channel “M-P9U (or Default Setting: 200W (FTDX101MP) 5-10)”...
  • Page 113 OPERATION SETTING DISPLAY SETTING - TUNING - - DISPLAY - SSB/CW DIAL STEP MY CALL Function: Setting of the MAIN dial tuning speed Function: Programs a Call Sign or Name. in the SSB and CW mode. Available Values: Up to 12 alphanumeric charac- Available Values: 5 / 10 (Hz) ters Default Setting: 10...
  • Page 114 DISPLAY SETTING DISPLAY SETTING - EXT MONITOR - - SCOPE - EXT DISPLAY Function: Sets the resolution of Spectrum Scope Function: Video signal output setting of the EXT- display. DISPLAY terminal on the rear panel. Available Values: HIGH / MID / LOW Available Values: OFF / ON Default Setting: HIGH Default Setting: OFF...
  • Page 115 The contents of the memory channel “M-01” will FTDX101 series is available, go to return to the initial setting “7.00.000 MHz, LSB” the YAESU web site to download the and cannot be deleted. programming data and update the FTDX101 series Firmware.

  • Page 116: Resetting The Microprocessor

    Resetting the Microprocessor Memory channels, setting menus, and various settings can be initialized and returned to their factory de- faults. FUNC key EXTENTION SETTING EXTENTION SETTING RESET DATE&TIME MEMORY CLEAR DONE SD CARD MENU CLEAR SOFT VERSION DONE CALIBRATION ALL RESET DONE RESET RESET...

  • Page 117: Optional Accessories

    Optional Accessories FC-40 External Automatic Antenna Tuner (for Wire Antenna) The FC-40 makes use of the control circuitry built into the transceiver, which allows the operator to control and monitor automatic operation of the FC-40, which mounts near the antenna feedpoint. The FC-40 uses specially selected, thermally stable components, and is housed in a waterproof case to withstand severe environmental conditions with high reliability.

  • Page 118: Setup The Ftdx101 Series

    ● When the optimum tuning point has been tenna connector connected with FC-40. • When using FC-40 with FTDX101MP, the reached, the transceiver will return to re- maximum transmit power of the antenna con- ceive, and the LED in the [TUNE] key will nector connected with FC-40 will be 100W again glow steadily (instead of blinking).

  • Page 119: Optional Fh-2 Control

    Optional FH-2 Control With the optional remote-control keypad FH-2 voice messages may be recorded and transmitted (Voice Memory). The FH-2 is also the control of the Contest Memory Keyer during CW operation. ● SSB / AM / FM modes have five voice memory channels (20 seconds each) for storage and playback, of voice recordings (page 54).

  • Page 120: Specifications

    31.5 lbs (14.3 kg): FTDX101MP 26.5 lbs (12 kg): FTDX101D Transmitter Power Output: FTDX101MP: 5 - 200 W (5 - 50 W AM carrier) FTDX101D: 5 - 100 W (5 - 25 W AM carrier) Modulation Types: J3E (SSB): Balanced...

  • Page 121: Receiver

    Receiver Circuit Type: Double Superheterodyne Intermediate Frequencies: 1 st: 9.005 MHz (MAIN), 8.9000 MHz (SUB) 2 nd: 24 kHz (MAIN/SUB) Sensitivity (TYP): SSB/CW (BW: 2.4 kHz/10 dB S+N/N) 1.8 MHz - 30 MHz 0.16 µV (AMP2 “ON”) 50 MHz - 54 MHz 0.125 µV (AMP2 “ON”) 70MHz - 70.5MHz 0.16µV (AMP2 “ON”)

  • Page 122: Index

    Index +13.8V ............. 17 Digital Noise Reduction ........45 3DSS ............... 25 Digital NOTCH Filter ........45 DISP ..............26 Display Indications ........... 20 DNF ..............45 About TFT Displays ......... 29 DNR ..............45 ACC ..............17 Accessories ............8 Adjustable Receiver Audio Filter ......
  • Page 123 Labeling Memories .......... 74 Rear Panel ............16 LEVEL ............. 27 REM ..............16 LINEAR ............17 Repeater Operation ......... 65 Linear Amplifier Interconnections ....14 Resetting the Microprocessor ......111 LOCK ............... 34 Reversing the Keyer Polarity ......60 R.FIL ..............
  • Page 124 USB ..............17 USB Jack ............32 Using the SD Card ........... 80 VC TUNE ............40 VFO Scanning ..........76 Voice Communications ........50 Voice Memory ..........54 VOX ..............33 VOX anti-trip sensitivity ........33 VOX Delay Time ..........33 VOX GAIN ............

  • Page 125: Yaesu Limited Warranty

    D. The Limited Warranty is valid only in the country/region where this product was originally purchased. E. During the Warranty Period, YAESU MUSEN will, at its sole option, repair or replace (using new or re- furbished replacement parts) any defective parts within a reasonable period of time and free of charge.
  • Page 126 YAESU MUSEN’S MAXIMUM LIABILITY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID FOR THE PRODUCT. IN NO EVENT SHALL YAESU MUSEN BE LIABLE FOR LOSS OF, DAMAGE TO OR CORRUPTION OF STORED DATA, OR FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR INDI- RECT DAMAGES, HOW EVER CAUSED;...
  • Page 127 6125 Phyllis Drive, Cypress, CA 90630, U.S.A. Telephone: (714) 827-7600 z Changes or modifications to this device that are not expressly approved by YAESU MUSEN could void the user’s authorization to operate this device. z This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: ( 1 ) This device may not cause harmful interference, and ( 2 ) this device must accept any interference including received, interference that may cause undesired operation.
  • Page 128 EU Declaration of Conformity We, Yaesu Musen Co. Ltd of Tokyo, Japan, hereby declare that this radio equipment FTDX101MP / FTDX101D is in full compliance with EU Radio Equipment Directive 2014/53/EU. The full text of the Dec- laration of Conformity for this product is available to view at http://www.yaesu.com/jp/red ATTENTION –...
  • Page 129 Copyright 2020 YAESU MUSEN CO., LTD. All rights reserved. No portion of this manual may be reproduced without the permission of YAESU MUSEN CO., LTD. YAESU MUSEN CO., LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan YAESU USA 2003m-GS-1 6125 Phyllis Drive, Cypress, CA 90630, U.S.A.
