Main Window; Starting A Freeze-Drying Process - Christ Alpha 3-4 LSCbasic Operating Manual

6.4.1.3

Main window "?"

NOTE
6.4.2

Starting a freeze-drying process

NOTE
NOTE
Version 11/2018, Rev. 1.2 of 05/03/2019 • sb-pe
Translation of the original operating manuel
This main window includes the most important information concerning your
freeze-dryer:
Fig. 49: Freeze-dryer system information (example)
In the event of enquiries at the manufacturer, please state the data that is
stated here.
Freeze-drying processes are started in the main window "Process".
Prior to any freeze-drying process, the correct method must be selected
(chapter 6.4.1.2 - "Main window "Options"", "Freeze-drying process (3)").
The set values for the individual process phases ("Freezing", "Warm-up",
"Main drying" and "Final drying") are defined prior to the start of the
process (see chapter 6.4.2.1 - "Entering set values"). Then, the freeze-
drying process can be started via the dialogue box "Operating mode:
select/start".
If the freeze-drying process is to be started directly with the "Main drying"
phase, the vacuum pump must be warmed up approximately 15 minutes
prior to the process start. Failure to do so will result in a corresponding
warning message when the process starts.
Freeze-dryer Alpha 3-4 LSCbasic
6 Operation
1 Freeze-dryer type
2 Control system type
3 Serial number
4 Manufacturer contact
data
5 Details concerning the
software version
65 / 97
