This section provides the list of available codes.
Once a code is selected, you can remove it from the
system by pressing the Delete button.
Instead the Program button will allow you to set its
parameters:
• Description, label that identifies the user and that is
shown in the events it is involved in.
• PIN, 5-figure number that identifies the user, thus
allowing access to the system.
• Type, determines the set of operations the user can
control. The following values are possible (refer to
paragraph 1.4 Operator classification - Access Levels and
the User manual):
- No code, code not enabled to access the system.
- User level, coincides with "Level 2" (authorized user)
- Superuser level, same as the previous level, with the
added possibility of loop-device replacement.
- Maintenance operator level, same as the previous level
with the added possibility of stopping the valve pulse
for those models that support extinction functions
- User level, coincides with "Level 3" (authorized user)
Previdia Compact control panels are supplied at default with
the first 4 codes already pre-set:
3.8

Configuring the communicator

To set the network parameters you must first enter the control panel programming phase (paragraph 2.2) and
then tap on the appropriate icon inside the control panel configuration screen.
The boxes marked [A] will allow you to select the
communication channels you want to use:
• Ethernet, for transmission of events with the SIA-IP
protocol over Ethernet cable
• PREVIDIA-C-DIAL, for transmission through the optional
communicator of the Previdia Compact.
If selected, the following channels will also become
available:
• SIM (SIA-IP), for transmission of events with the SIA-IP
protocol over 3G
• SIM (Voice/SMS), for transmission of events with
Contact-ID protocol, of voice messages or SMS texts
over 3G
• PSTN, transmission of events with Contact-ID protocol or
voice messages over the landline
The APN button [B] provides access to a section for the parameters required for the connection to the mobile network.
The Contacts button [C] accesses the phone book programming phase.
After selecting a contact, you will be able to configure it by pressing the Program button.
16
Code number
1
2
3
4
5 ...
N. Type
1 User level
2 Superuser level
3 Maintenance level
4 Installer level
5 No code
6 No code
Delete Program
Access
level:3
Code parameters
Code 2
User level
Access
level:3
Code type
User level
Superuser level
Maintenance level
Installer level
No code
PREVIDIA-C-DIAL
SIM (SIA-IP)
SIM (voice/SMS)
PSTN
Access
level:3
Fire detection and extinguishant system
Description
Code 1
Code 2
Code 3
Code 4
Code 5
Code 6
Description
PIN
Type
Default PIN
00001
00002
00003
00004
/
A
Ethernet
APN
Contacts
Actions
Esc
Esc
Set
B
C
Esc
D
Set
